User's Guide

A20-MINI User Guide
12
Active A20-MINI in the TX View
The active A20-MINI in the TX View is indicated by the indent on
the right-hand side of the TX List. Touch any transmitter in the
TX List to make it the active transmitter.
Audio Signal Presence/Mic Mute
The Mic icon varies in intensity when audio
signal is present. Touch the Mic icon to mute
the microphone. To prevent accidental muting,
aconrmationdialogpopupappearsaskingto
conrmthechange.Whenmuted,noaudiois
present in the recordings or transmitted.
Transmitter Power
Touch the Power icon to turn the A20-MINI on
oro.Theiconwillbegraywhenthetransmit-
terisoandwhitewhenthetransmitterison.
Record
Touch the Record icon to start a recording on
the A20-MINI. The icon is red while recording.
Stop
Touch the Stop icon to stop a recording on the
A20-MINI. The icon is yellow while recording is
stopped.
Files View
On a phone, touch the SSD icon to see the
A20-MINI Files View. See Files View for more
information.
License Required
Some frequencies may require a license to
operate on in your area. The LIC icon appears
if the set frequency requires a license for your
location.
Controlling A20-MINI from SD-Remote
While in the TX View, touch the A20-MINI from the TX List you
wish to control or view in more depth. The selected transmitter
is displayed to the immediate right of the TX List.
From the TX View you can control parameters of the A20-MINI
and get a detailed view of audio signal presence, timecode, and
more.
Naming the A20-MINI
WhileintheTXView,touchthenameeldandusethepopup
QWERTY keyboard to rename the transmitter. You are allowed
up to twelve alpha-numeric characters. The transmitter’s name
is the serial number of the unit by default. Names are tied to
User Group frequency when using User Groups. See User
Groups for more detail.
