13/24
HART
Command
Description
Command Data Command Reply Data
Byte Description Byte Description
34
Write PV
damping value
0-3
Dampaing value
(seconds)
0-3 Dampaing value (seconds)
35
Write PV range
values
0
Range units
code
0 Range units code
1-4
Upper range
value
1-4 Upper range value
5-8
Lower range
value
5-8 Lower range value
36
Set PV as upper
range value
None Write only
37
Set PV as lower
range value
None Write only
38
Reset
configuration
changed flag
0-1
Configuration
change flag
0-1 Configuration change flag
40
Enter/Exit fixed
current mode
0-3
Current (mA), 0
to exit
0-3 Current (mA), 0 to exit
41
Perform self
test
None Write only
42
Perform device
reset
None Write only
43 Set PV zero None Write only
44 Write PV units 0 PV units code 0 PV units code
45
Trim loop
current zero
0-3
Trim loop
current zero
value
0-3 Trim loop current zero value
46
Trim loop
current gain
0-3
Trim loop
current gain value
0-3 Trim loop current gain value
47
Write PV
transfer function
0
Transfer function
code
0 Transfer function code
48
Read additional
device status
0
Device-Specific
Status Byte 0
0 Device-Specific Status Byte 0
1
Device-Specific
Status Byte 1
1 Device-Specific Status Byte 1
2
Device-Specific
Status Byte 2
2 Device-Specific Status Byte 2
3
Device-Specific
Status Byte 3
3 Device-Specific Status Byte 3
4
Device-Specific
Status Byte 4
4 Device-Specific Status Byte 4
