4-4 CUE Menu
4-42 Chapter 4 Menu Settings
Chapter 4 Menu Settings
CUE
SCAN
CH.COND
TELE FILE
TCR 00:00:00:00
COMMNT
EDIT
ENTRY
POINT
CHANGE
DATA
DEL
POINT
MARK PRO-
TECT
TAPE
INFO
CUENUM
POINT
WRITE/
EXIT
REC DATE[1998/02/10] Rest 50%
No. Comment
1 Noisy
2 Holiday
3 Pretty Good
4 for NG Awards
5 Goal
6 Celebration
7
TITLE[NAGANO JUMP LARGE HILL]
CUE
SCAN
CH.COND
TELE FILE
TCR 00:00:00:00
COMMNT
EDIT
ENTRY
POINT
CHANGE
DATA
DEL
POINT
MARK PRO-
TECT
TAPE
INFO
CUENUM
POINT
WRITE/
EXIT
REC DATE[1998/02/10] Rest 50%
No. OUT Tk Cut Scn
1 00:01:02:03 1 0015 A01
2 --:--:--:-- 2 0015 A01
3 00:03:04:03 3 0015 A01
4 00:04:05:03 1 017~ A01
5 00:05:06:03 1 B20
6 00:06:07:03 2 B20
7 --:--:--:--
TITLE[NAGANO JUMP LARGE HILL]
CUE
SCAN
CH.COND
TELE FILE
TCR 00:00:00:00
COMMNT
EDIT
ENTRY
POINT
CHANGE
DATA
DEL
POINT
MARK PRO-
TECT
TAPE
INFO
CUENUM
POINT
WRITE/
EXIT
REC DATE[1998/02/10] Rest 50%
No. IN OUT
1 00:01:02:03 00:01:03:03
2 --:--:--:-- --:--:--:--
3 00:03:04:03 00:04:05:03
4 00:04:04:03 00:05:05:03
5 00:05:05:03 00:06:06:03
6 00:06:06:03 00:07:05:03
7 --:--:--:--
TITLE[NAGANO JUMP LARGE HILL]
CUE
SCAN
CH.COND
TELE FILE
TCR 00:00:00:00
COMMNT
EDIT
ENTRY
POINT
CHANGE
DATA
DEL
POINT
MARK PRO-
TECT
TAPE
INFO
CUENUM
POINT
WRITE/
EXIT
REC DATE[1998/02/10] Rest 50%
No. Time Mrk IN
0 00:01:02:03 NG 00:01:01:03
1 --:--:--:-- KP --:--:--:--
2 00:03:04:03 OK @ 00:03:03:03
3 00:04:04:03 OK 00:04:03:03
4 00:05:05:03 NG 00:05:04:03
5 00:06:06:03 OK 00:06:05:03
6 --:--:--:--
TITLE[NAGANO JUMP LARGE HILL]
Four levels of information can be displayed in the TELE File menu and the levels can be scrolled to the left or
right by pressing the [<] or [>] button.
TELE FILE menu display 1
TELE FILE menu display 2
1REC DATE
Displays the date the memory label contents were last
modified.
2TITLE
Displays the cassette title.
3Time
Displays the time data of the cue point.
4Mrk
Displays the cue point attribute (OK/NG/KP/no
attribute).
5Recording start point setting
Recording start points are indicated by an @ mark.
6IN
Displays IN point data.
7OUT
Displays OUT point data.
TELE FILE menu display 3
TELE FILE menu display 4
8Tk
Displays the take number of the cue point.
9Cut
Displays the cut number of the cue point.
!ºScn
Displays the scene number of the cue point.
!¡Comment
Displays the comment for a cue point.
Line number
1
2
345
67
89!º
!¡
