4-4-7 TELE FILE Menu
Use the TELE FILE menu to read and update cue point
information, log(IN/OUT points) information and
cassette-management information on optional MLB-
1B-100 memory labels.
Operations through the TELE FILE menu can be
carried out from either the control panel of the VTR or
a personal computer connected to the VTR. To use the
control panel, specify “control panel” for item
123.Tele-File CONTROL MODE in the VTR SETUP
menu. To use a personal computer, specify “RS-
232C.”
Note
Before you can use the menu to operate the VTR from
a personal computer, the optional MLZ-100 memory
label application software must be installed in the
computer.
For details on the use of a personal computer, refer to the
operation manual supplied with the optional MLZ-100
memory label application software.
The explanations of menu operations in this chapter
assume the use of the VTR control panel.
Opening the TELE FILE menu
Do one of the following:
• Press the [F4] (TELE FILE) button while in the CUE
menu.
• Select “on” for item 124.Tele-File MENU auto popup
in the VTR SETUP menu. Then, with the HOME,
TC, CUE, or SETUP menu open, insert a cassette
bearing an optional MLB-1B-100 memory label into
the VTR.
To change the information displayed in the
TELE FILE menu
Press the [<] or [>] button.
To display log data (IN or OUT points) in the
TELE FILE menu
Do one of the following:
• Press the [F2] (ENTRY POINT) button while in the
TELE FILE menu. Then select “INPUT.”
• Select “IN/OUT Point” for item 126.Tele-File
ENTRY POINT in the VTR SETUP menu.
Exiting the TELE FILE menu
Press the [F10] (WRITE/EXIT) button. The entered or
modified data is saved to the memory label and the
VTR exits the TELE FILE menu.
Note
If TELE FILE menu operations are prohibited (see
page 4-39) while the contents of a memory label are
being modified, only the data modified prior to the
prohibition will be saved to the memory label when the
[F10](WRITE/EXIT) button is pressed.
To exit the TELE FILE menu without saving
data to a memory label
Press the EJECT button. Or, press the ALT/[F2]
(UNDO ALL) buttons to display a message (in the
control panel display) requesting confirmation of the
undoing operation. Then press the [F2](UNDO ALL)
button while pressing down the SFT button. All
changes to the memory label will be cancelled.
Note
When you press the EJECT button, all controls on the
VTR will become inoperable until the cassette is
completely ejected.
If you accidentally press the EJECT button
before saving data to a memory label
Insert the cassette again within 30 seconds after the
ejection and press the [F10](WRITE/EXIT) button.
The data that existed before the ejection of the cassette
is saved to the memory label.
