Chapter 4 Menu Settings 4-19
Chapter 4 Menu Settings
4-2-9 Recalling Edit Points
(LAST EDIT)
While editing, you can recall the last edit points by
pressing the ALT button, then the [F10] (LAST EDIT)
button.
The edit points appear in the display.
Recalling edit points (LAST EDIT)
4-2-8 Selecting DMC Playback
(DMC)
In DMC (Dynamic Motion Control) playback mode,
the VTR plays back a tape segment at a specified
variable speed of –1 to +2 times normal playback
speed, memorizes the speed, then plays the segment
back at a later time at the memorized speed.
DMC playback is useful during on-the-spot telecasts of
sporting events for immediate playback and broadcast
of highlight scenes for which starting and ending
points have been set during recording.
For detail on the procedure for DMC playback, see Section
5-4-4, “DMC Playback” on page 5-14.
During tape editing using two HDW-F500 VTRs, you
can use DMC playback to control the playback speed
of the player VTR for editing at variable speeds (DMC
editing).
For detail on the procedure for DMC editing, see Section
6-2-1, “Performing DMC Editing” on page 6-15.
Edit points
ÅIN 00:01:10:00 ÅOUT 00:02:10:00
PLAY LOCK
PB/EE
CH.COND
GREEN
BÅSEBÅLL EDIT SET
HOME
TCR 2FD F1
IN 00:01:10:00 OUT 00:02:10:00
01Ó 04µ 58ß 00ƒ
RECINH
off
PB
ÅSSEM-
BLE
off
INS
TC
off
INS
VIDEO
off
INS
Å-CH1
off
INS
Å-CH2
off
INS
Å-CH3
off
INS
Å-CH4
off
INS
CUE
off
