Chapter 4 Menu Settings 4-1
Chapter 4 Menu Settings
4-1-1 Menu Configuration
This VTR has two kinds of menus.
PF1&2 ASSIGN menu
This menu contains items that can be registered to the
PF1/2 menus.
Press the [F4] (PF1&2 ASSIGN) button in the SET UP
menu to display this menu.
For details on registering items in the PF1&2 ASSIGN
menu to the PF1/2 menus, see Section 4-1-3, “Registering
Items to the PF1/2 Menus” on page 4-3.
VTR SETUP menu
This menu contains items that specify the initial
operating conditions of the VTR. You can change
these settings directly without registering the items to
the PF1/2 menus.
Press the [F6] (VTR SETUP) button in the SET UP
menu to display this menu.
For details on setting operating conditions of the VTR, see
Section 4-7-1, “VTR SETUP Menu” on page 4-61.
The menu configuration of the VTR is shown in the
figure below,
Menu configuration
• All items in the HOME, TC, and CUE menus can be
duplicated and registered to the PF1/2 menus.
• Most items in the VTR SETUP menu can be
registered to the PF1/2 menus.
4-1 Registering and Storing Menu Settings
Chapter 4 Menu Settings
The operating conditions of the VTR are set using the
menu operation section on the lower control panel.
Menu items are divided among six different menus
(HOME, TC, CUE, PF1, PF2, SET UP).
Of these menus, the PF1/PF2 (Personal Function)
menus can be used to register frequently used menu
items from the other menus, allowing faster setting of
VTR operating conditions. Eight VTR memory banks
are provided for storing up to eight sets of menu
settings. The contents of the eight VTR memory
banks can, in turn, be stored on a memory card for
later recall.
VTR SETUP
menu
SETUP menu
HOME menu
TC menu
PF1 menu
PF2 menu
CUE menu
PF1&2
ASSIGN menu
Registration
[F4]
(PF1&2 ASSIGN) button
[F6] (VTR SETUP) button
