Menu List
A-46 Appendix
Appendix
Other Items (T01~)
The values enclosed in a box are the factory settings.
Item number Settable range FunctionItem
T01
AUTO REPEAT
MODE
[off]
on
Selects the repeating operation in automatic editing.
off: Automatic editing is not repeated.
on: Automatic editing is repeated. To stop, press the STOP
button.
T02 INTERNAL VIDEO
SIGNAL
GENERATOR (HD)
[off]
COLOR BARS
MULTIBURST
10 STEPS
PULSE & BAR
[RAMP]
BLACK
Selects the test signal output by the signal generator built
into the VTR.
off: The test signal is not generated, and the VTR operates
normally.
all other settings: The test signal is output from the VTR. At
this time it is also possible to record the signal.
T03 INTERNAL VIDEO
SIGNAL LINE
SELECT
1035
[1080]
Selects the effective scanning line number of the test signal
output by the signal generator built into the VTR.
1035: Sets the effective scanning line number to 1035.
1080: Sets the effective scanning line number to 1080.
Note
This setting is only active when the frame frequency of the
unit is 29.97 Hz or 30 Hz.
Note
Items T01, T02, and T04 are reset whenever the power is turned off. Item T03 is maintained even when the power
is turned off.
T04 INTERNAL AUDIO
SIGNAL
GENERATOR
[off]
silence
1 kHz sine
Selects the operation of audio test signal output.
off: The audio test signal is not output.
silence: Mute signal.
1 kHz sine: 1 kHz (In this case, a 1 kHz -20 dB FS sine
wave is supplied to all audio inputs.)
Note
• When “silence” or “1 kHz sine” is selected, the AUDIO
INPUT/MONITOR SELECT buttons light up.
• When the unit is operated i n the 23.98 PsF or 24 PsF
mode with “1 kHz sine” selected, the output signal is 960
Hz.
