Appendix A-45
Appendix
Item number Settable range FunctionItem
A06
PD
SUPERIMPOSED
TIME CODE ID
[off]
on
When item 620 and A03 is set to “on,” specifies whether or
not the ID (24F/30F) is displayed to the right of
superimposed time code.
off: No ID is displayed.
on: ID (“24F” or “30F”) is displayed.
Note
The setting of this item is effective only when the operation
mode of this unit is set to 23.98PsF or 24PsF.
A07 PD CHARACTER
24F TIME CODE
MODE
[off]
on
When item 620 and A03 is set to “on,” specifies whether or
not the 2-3 pull down 24-frame time data is inserted to the
first line instead of 30-frame time data.
off: 30-frame time data is displayed.
on: 24-frame time data is displayed.
Note
The setting of this item is effective only when the operation
mode of this unit is set to 23.98PsF or 24PsF.
A10 TC sense data
select
[24F]
30F
When an HKDV-507D (optional HD Pull Down Board) is
installed and the operating frequency is set to 23.976PsF,
specifies whether or not the 30-frame/sec time code
information of pull down output signal and down-converted
output signal is returned when time code sense command
is input through the 9-pin connector.
24F: 24-frame/sec time code information of main output
signal is returned.
30F: 30-frame/sec time code information of pull down
output signal and down-converted output signal is
returned.
Notes
• Pull down output signal and 30-frame/sec time code are
synchronized only when this unit is set to PLAY LOCK
mode. To synchronize the signals, set item A05. PD EXT
SD REF LOCK MODE to “lock2.”
• Machine-to-machine editing using the pull down output
signal with a VTR operating in 30F mode may not function
properly if the VTR in 30F mode is engaged in player sync.
