Appendix A-41
Appendix
Item Settable rangeItem number Function
820 NON AUDIO
Channel select
[off]
SDI CH12 (MODE1)
SDI CH34 (MODE2)
SDI all (MODE3)
AES CH12 (MODE4)
AES CH34 (MODE5)
AES all (MODE6)
SDI CH12/AES CH34
(MODE7)
SDI CH34/AES CH12
(MODE8)
Selects the audio signal and the channels to be recorded as
non-audio data.
off: Non-audio signals are not recorded.
SDI CH12 (MODE1): Channels 1 and 2 of the signal input
from the HD/SDI INPUT connector are recorded.
SDI CH34 (MODE2): Channels 3 and 4 of the signal input
from the HD/SDI INPUT connector are recorded.
SDI all (MODE3): Channels 1 to 4 of the signal input from
the HD/SDI INPUT connector are recorded.
AES CH12 (MODE4): Channels 1 and 2 of the signal input
from the AUDIO INPUT (AES/EBU) connector are
recorded.
AES CH34 (MODE5): Channels 3 and 4 of the signal input
from the AUDIO INPUT (AES/EBU) connector are
recorded.
AES all (MODE6): Channels 1 to 4 of the signal input from
the AUDIO INPUT (AES/EBU) connectors are recorded.
SDI CH12/AES CH34 (MODE7): Channels 1 and 2 of the
signal input from the HD/SDI INPUT connector and the
channels 3 and 4 of the signal input from the AUDIO
INPUT (AES/EBU) connector are recorded.
SDI CH34/AES CH12 (MODE8): Channels 3 and 4 of the
signal input from the HD/SDI INPUT connector and the
channels 1 and 2 of the signal input from the AUDIO
INPUT (AES/EBU) connector are recorded.
821
AUDIO ADVANCE
MODE
[off]
on
Specifies whether or not the phase of the audio output signal
is shifted 1 frame ahead of the video output signal.
off: The phase of the audio output signal is not shifted.
on: The phase of the audio output signal is shifted 1 frame
ahead of the video output signal. Note that the phase is
shifted for all audio channels.
Note
When edit preset is set to “ON”, HDW-F500 operates
internally with “off” setting.
