Appendix A-39
Appendix
Items Related to the Audio Control (801~)
The values enclosed in a box are the factory settings.
Item Settable rangeItem number
811 DIGITAL AUDIO
FADE TIME
5 ms
[10ms]
15 ms
20 ms
25 ms
a)
50 ms
b)
85 ms
115 ms
c)
Specifies the fade processing time during cross-fading or
fading-in/out of digital audio signals.
Note
Processing for cross fading, fading-in, and fading-out starts
after an IN or OUT point. This item specifies rewriting
during recording following the OUT point. Rewriting of one
field occurs even when the minimum setting (5 ms) is
selected. When “cut edit” is selected in item 317 to prevent
this from happening, a discontinuity in the audio signal
occurs. There is, however, no effect on the recording of the
video signal.
a) The cross fade time is 24 ms.
b) The actual fade time is 49 ms.
c) The actual fade time is 114 ms.
Function
801 AUDIO INPUT
select
ALL-CHANNELS
analg
[SDI]
AES/EBU
[SDTI]
Selects the type and channels of the audio input signals.
analg: Audio signals input to the ANALOG AUDIO INPUT
connectors.
SDI: Audio signals input to the HD SDI INPUT connectors.
AES/EBU: Audio signals input to the AUDIO INPUT (AES/
EBU) connectors.
[SDTI] (Only when the optional HKDV-506A SDTI Board is
installed.): If “SDTI” is selected in item 701., the SDTI
audio signal input to the SDTI (OPTION) IN connector is
automatically selected and AUDIO INPUT/MONITOR
SELECT buttons on the upper control panel become
unlit and another input selection cannot be made.
802 AUDIO INPUT
select
CH-1
analg
[SDI]
AES/EBU
[SDTI]
803 AUDIO INPUT
select
CH-2
analg
[SDI]
AES/EBU
[SDTI]
804 AUDIO INPUT
select
CH-3
analg
[SDI]
AES/EBU
[SDTI]
805 AUDIO INPUT
select
CH-4
analg
[SDI]
AES/EBU
[SDTI]
806 AUDIO EMPHASIS [off]
on
Selects the emphasis mode when recording digital audio
signals converted from analog input audio signals.
off: Emphasis is not applied to any of the audio signals.
on: Emphasis is applied to all of the audio signals.
807 AUDIO MONITOR-
L select
[ch1]
ch2
.
.
.
ch1, ch2, ch3, ch4, cue
Selects the audio channel output from the AUDIO
MONITOR OUTPUT L connector.
808 AUDIO MONITOR-
R select
ch1
[ch2]
.
.
.
ch1, ch2, ch3, ch4, cue
Selects the audio channel output from the AUDIO
MONITOR OUTPUT R connector.
809 DIGITAL JOG
SOUND
off
[on]
Switches digital jog sound on and off.
off: Digital jog sound is switched off.
In this case, the sound for channels for which speed
correction processing is not being carried out is output,
even in the case of “STILL.”
on: Digital jog sound is switched on.
