Appendix A-37
Appendix
Item number Item Function
Settable range
766 H CROP POSITION
preset: 0
–120
.
.
.
[0]
.
.
.
120
When an HKDV-501A (optional HD-SD Converter Board) is
installed, ad justs the image enhancer. Adjust s the “H cr op”
(cropping position in the horizontal direction when using
edge crop mode).
767 DETAIL GAIN
pr eset: 32
0
.
.
.
[32]
.
.
.
127
When an HKDV-501A (optional HD-SD Converter Board) is
installed, ad justs the image enhance r. Adjusts the degree of
edge enhancement.
768 LIMITER
pr eset: 32
0
.
.
.
[32]
.
.
.
63
When an HKDV-501A (optional HD-SD Converter Board) is
installed, ad justs the image enhancer . Adjust s the maxi mum
level of the detail added to enhance the original signal.
769 CRISP THRESHOLD
preset: 0
[0]
.
.
.
15
When an HKDV-501A (optional HD-SD Converter Board) is
installed, ad justs the image enhancer. Sets the amplitude
for not enhancing small-amplitude signals.
760 CHROMA LEVEL
(D2)
preset: 100%
(4000H)
0.0% (0H)
.
.
.
[100%ª4000Hº]
.
.
.
141.3% (5A70H)
Adjusts the chroma level of the D2 video signal output from
D CONV. SDI OUT (OPTION) connector and analog
composite video signal output from D CONV. OUT
(OPTION) COMPOSITE (SUPER) connector.
761 HUE (D2)
preset: 0
–30
.
.
.
[0]
.
.
.
30
Adjusts the hue of the D2 video signal output from D CONV.
SDI OUT (OPTION) connector and analog composite video
signal output from D CONV. OUT (OPTION) COMPOSITE
(SUPER) connector.
762 SETUP LEVEL
(D2)
preset: 7.5 IRE
0.0
.
.
.
[7.5]
.
.
.
10.0
Adjusts the setup level of the D2 video signal output from D
CONV. SDI OUT (OPTION) connector and analog
composite video signal output from D CONV. OUT
(OPTION) COMPOSITE (SUPER) connector.
763 SYNC PHASE (SD)
preset: 0
–128
.
.
.
[0]
.
.
.
127
Adjusts the sync phase of the D1/D2 video signal output
from D CONV. SDI OUT (OPTION) connectors and analog
composite video signal output from D CONV. OUT
(OPTION) COMPOSITE (SUPER) connector.
764 FINE (SD)
preset: 0
[0]
.
.
.
1024
Makes fine adjustments to the sync phase of the D1/D2
video signal output from D CONV. SDI OUT (OPTION)
connectors and analog composite video signal output from
D CONV. OUT (OPTION) COMPOSITE (SUPER)
connector.
765 CROSS COLOR
preset: 8
0
.
.
.
[8]
.
.
.
15
When an HKDV-501A (optional HD-SD Converter Board) is
installed, adjusts the image enhancer.
