Appendix A-35
Appendix
Item number Item FunctionSettable range
710 PB LEVEL (HD)
preset: 100%
(4000H)
0.0% (0H)
.
.
.
[100%ª4000Hº]
.
.
.
141.3% (5A70H)
Adjusts the level of the HD video signal output from the HD
SDI OUTPUT connectors. Adjusts the P
B level of the video
signal.
711 PR LEVEL (HD)
preset: 100%
(4000H)
0.0% (0H)
.
.
.
[100%ª4000Hº]
.
.
.
141.3% (5A70H)
Adjusts the level of the HD video signal output from the HD
SDI OUTPUT connectors. Adjusts the P
R level of the video
signal.
712 SETUP LEVEL
(HD)
preset: 0
–10.0
.
.
.
[0.0]
.
.
.
10.0
Adjusts the level of the HD video signal output from the HD
SDI OUTPUT connectors. Adjusts the setup level of the
video signal.
713 SYNC PHASE (HD)
preset: 0
–128
.
.
.
[0]
.
.
.
127
Controls the H sync phase of the HD video signal output
from the HD SDI OUTPUT connectors, according to the
menu.
714 FINE (HD)
preset: 0
[0]
.
.
.
1024
Controls the H sync phase of the HD video signal output
from the HD SDI OUTPUT connectors, according to the
menu.
720 EFFECT EDIT
MODE
[off]
on
Applies effect edit mode for editing special effects or for
dubbing a tape with an attenuated signal-to-noise ratio.
off: For normal editing or dubbing.
on: For repeated editing of special effects or for dubbing a
tape with a highly attenuated signal-to-noise ratio.
730 ACTIVE LINE 1035
CONVERT MODE
1080÷1035(CONV)
1080÷1035(CROP)
When the HKDV-502 HD Line Converter Board is installed,
selects the conversion mode of the effective scanning line
number.
1080÷1035(CONV): Convert the effective scanning line
number from 1080 to 1035 preserving the aspect ratio of
the image.
1080÷1035(CROP): Convert the effective scanning line
number from1080 to 1035. The four sides of the image
are cropped, then it is horizontally expanded.
731
ACTIVE LINE 1080
CONVERT MODE
1035÷1080(CONV)
1035÷1080(PANEL)
When the HKDV-502 HD Line Converter Board is installed,
selects the conversion mode of the effective scanning line
number.
1035÷1080(CONV): Convert the effective scanning line
number from 1035 to 1080 preserving the aspect ratio of
the image.
1035÷1080(PANEL): Convert the effective scanning line
number from 1035 to 1080. The 1035 lines of the image
are inserted into the 1035 lines of 1080 lines, then it is
horizontally compressed.
732
SLOW PROCESS
MODE
[on]
off
When the HKDV-502 HD Line Converter Board is installed,
selects whether or not to activate the function to improve the
vertical resolution during slow-motion playback.
on: Activate the function to improve the vertical resolution
during slow-motion playback.
off: Do not activate the function to improve the vertical
resolution during slow-motion playback.
Note
This setting has no effect when the VTR is operated in PsF
mode.
