Item number Item Settable range
Specifies the signal output to the TIME CODE OUT
connector when the internal time code generator is in a
mode for regenerating the playback time code (i.e. during
auto edit mode or when item 607. is set to int-LTC or int-
VITC and item 606. is set to “regene”.)
off tape: The playback time code signal is output to the
TIME CODE OUT connector without regeneration.
regene: The playback time code signal is output to the
TIME CODE OUT connector after regeneration only
when the VTR is in playback mode.
through: The playback time code signal is output.
613 TC OUTPUT
SIGNAL IN
REGENE MODE
614 PHASE
CORRECTION
[off]
on
[off]
on
auto
TCG CF FLAG Specfies whether the color frame (CF) flag is set (ON) or
not set (OFF) in the blank bit of the time code data.
off: Color frame flag is set OFF.
on: Color frame flag is set ON.
auto: Color frame flag is set ON or OFF depending on the
phase relationship of the color framing between the
recorded video signal and the time code signal.
615
[offtape]
regene
through
Specifies whether the phase correction control of the LTC
signal generated by the time code generator is applied or
not.
off: The phase correction control is not applied.
on: The phase correction control is applied.
616 VITC POSITION-1
select (PAL)
9,322 line
.
.
.
[19,332line]
.
.
.
22,335 line
When an HKDV-501A (optional HD-SD Converter Board) is
installed and 25PsF/50i mode is selected on the VTR, this
setting specifies the lines in which the VITC signal is
inserted.
It can be inserted in any lines from 9,322 to 22,335.
Note
Items 616 and 617 allow VITC to be inserted in two lines.
617 VITC POSITION-2
select (PAL)
9,322 line
.
.
.
[21,334line]
.
.
.
22,335 line
When an HKDV-501A (optional HD-SD Converter Board) is
installed and 25PsF/50i mode is selected on the VTR, this
setting specifies the lines in which the VITC signal is
inserted.
It can be inserted in any lines from 9,322 to 22,335.
Note
Items 616 and 617 allow VITC to be inserted in two lines.
Note
When this item is set to “auto”, the color frame flag is
determined by the operating mode of the time code
generator.
• When PRESET mode (i.e., item 606 is set to preset and
the VTR is in a mode other than automatic edit mode), the
time code signal is generated with color flame-locked to
the video signal, and the color frame flag is ON.
• When REGENE mode (i.e., item 606 is set to regene or
the VTR is in automatic edit mode), color frame flag is
OFF.
620
SUPERIMPOSED
CHARACTER
[off]
on
Specifies whether or not to superimpose time data and
operating status information on the signal output from the
MONITOR connector of HD SDI OUTPUT, the D CONV.
OUT (OPTION) COMPOSITE (SUPER) connector and the
3 (SUPER) connector of D CONV. SDI OUT (OPTION).
off: No information is superimposed.
on: Information is superimposed.
Function
