Appendix A-23
Appendix
The values enclosed in a box are factory settings.
Items Related to Remote Interface (201~)
Item number Item Settable range Function
201 REMOTE 9-PIN [off]
on
When this is set to “on,” this unit is controlled from the
device connected to the REMOTE 1-IN(9P)/OUT(9P)
connectors.
Note
When this unit is controlled by a device connected to the
REMOTE 1-IN(9P) or PARALLEL I/O 1-IN(50P)
connectors, the editing control buttons and all of the tape
transport buttons except STOP and EJECT are disabled. It
is also possible to make a setting so that all of the buttons
are disabled.
For details, see item 008.
202 REMOTE 50-PIN [off]
on
When this is set to “on,” this unit is controlled from the
device connected to the REMOTE PARALLEL I/O (50P)
connector (optional BKDW-509).
203 PARALLEL
RUNNING
[disable]
enable
Selects whether two or more VTRs can be operated
synchronized.
disable: Synchronized operation is not carried out.
enable: Synchronized operation is enabled.
Note
For synchronized operation to be possible, item 203 must
be set to “enable” on all of the connected VTRs.
