Menu List
A-18 Appendix
Appendix
Item number Item Settable range Function
009
LOCAL KEY MAP Enables/disables the buttons on this unit when it is in remote
control mode.
Sub items
STOP [disable]
enable
disable: The STOP button is disabled in remote control
mode.
enable: The STOP button operates in remote control mode.
PLAY [disable]
enable
disable: The PLAY button is disabled in remote control
mode.
enable: The PLAY button operates in remote control mode.
REC/EDIT [disable]
enable
disable: The REC/EDIT button is disabled in remote control
mode.
enable: The REC/EDIT button operates in remote control
mode.
STANDBY [disable]
enable
disable: The STANDBY button is disabled in remote control
mode.
enable: The STANDBY button operates in remote control
mode.
EJECT [disable]
enable
disable: The EJECT button is disabled in remote control
mode.
enable: The EJECT button operates in remote control mode.
JOG [disable]
enable
disable: The JOG button is disabled in remote control mode.
enable: The JOG button operates in remote control mode.
SHUTTLE [disable]
enable
disable: The SHUTTLE button is disabled in remote control
mode.
enable: The SHUTTLE button operates in remote control
mode.
VAR [disable]
enable
disable: The VAR button is disabled in remote control mode.
enable: The VAR button operates in remote control mode.
PREROLL [disable]
enable
disable: The PREROLL button is disabled in remote control
mode.
enable: The PREROLL button operates in remote control
mode.
PREVIEW/
REVIEW
[disable]
enable
disable: The PREVIEW/REVIEW button is disabled in
remote control mode.
enable: The PREVIEW/REVIEW button operates in remote
control mode.
AUTO [disable]
enable
disable: The AUTO button is disabled in remote control
mode.
enable: The AUTO button operates in remote control mode.
INPUT CHECK [disable]
enable
disable: The INPUT CHECK button is disabled in remote
control mode.
enable: The INPUT CHECK button operates in remote
control mode.
MENU&CURSOR [disable]
enable
disable: The menu buttons and the cursor control buttons
are disabled in remote control mode.
enable: The menu buttons and the cursor control buttons
operate in remote control mode.
AUDIO INPUT [disable]
enable
disable: The AUDIO INPUT button is disabled in remote
control mode.
enable: The AUDIO INPUT button operates in remote
control mode.
MONITOR [disable]
enable
disable: The MONITOR button is disabled in remote control
mode.
enable: The MONITOR button operates in remote control
mode.
