Menu List
A-16 Appendix
Appendix
The values enclosed in a box are factory settings.
Items Related to VTR Operations (001~)
Item number Item Settable range Function
001 PRE-READ [off]
audio/video
audio only
video only
Selects the pre-read (read-before-write) mode for insert
editing.
off: No pre-read operation
audio/video: Carry out pre-read editing for both audio and
video
audio only: Carry out pre-read editing for audio only
video only: Carry out pre-read editing for video only
002 REC INHIBIT
select
[off]
all/crash REC/video
CTL/audio CTL
Selects the record inhibit mode.
off: Recording is enabled. (The REC INHIBIT indicator does
not light.)
all/crash/video/audio: Recording is inhibited on the set
channels. (The REC INHIBIT indicator either lights or
goes off.)
The scope of inhibiting recording is determined by menu
item 003.
003 REC INHIBIT
AREA select
[all]
crash REC
video/CTL
audio/CTL
[casst]
Selects the scope to which inhibiting recording applies.
all: All recording is inhibited. (The REC INHIBIT indicator
lights.)
crash REC: The normal recording mode is inhibited. Use this
setting when you wish to record in assemble editing or
insert editing only.
video/CTL: Recording of video and CTL is inhibited.
audio/CTL: Recording of audio and CTL is inhibited.
[casst]: When the recording protection plug on the cassette
is pushed in, this setting is displayed. This setting cannot
be selected.
The REC INHIBIT indicator lights or flashes to indicate the
state of the recording inhibit mechanism on the cassette.
For details, see item 104.
004 CAPSTAN LOCK
select
[2FD]
4FD
When editing or playing back a tape with decoded
component signals, select the appropriate setting depending
on your purpose.
2FD: This setting locks the capstan servo in two-field units.
This is the normal setting for editing or playing back HD
or D1 signals.
4LOCK: The capstan servo is locked to the color frame
every 4 fields. If color frames occur intermittently during
playback, the capstan servo is locked when the next
color frame appears.
4HOLD: The capstan servo is locked to the color frame
every 4 fields. If color frames occurs intermittently
during playback, the capstan servo stays locked to that
color frame.
Note
•This setting is only active when the frame frequency of the
unit is 29.97 Hz or 30 Hz.
•To lock composite signal output to four fields on this VTR,
set item 005. to external and 006. to extern SD.
