Appendix A-15
Appendix
Items in the VTR SETUP menu are divided into
categories according to type of setting they perform.
Descriptions on each item are given below:
• Items related to the hours meter (H01~)
• Items related to VTR operations (001~)
• Items related to operation panels (101~)
• Items related to the remote interface (201~)
• Items related to editing (301~)
• Items related to prerolling (401~)
Menu List
• Items related to recording protection (501~)
• Items related to the time code (601~)
• Items related to the video control (701~)
• Items related to the audio control (801~)
• Items related to digital process (901~)
• Items related to pull down control (A01~)
• Other items (T01~)
For details on the VTR SETUP menu, refer to “4-7-1 VTR
SETUP Menu” on page 4-61.
Items Related to the Hours Meter (H01~)
H01
Displays the total number of hours that the VTR has been turned on and operated.
Item number Item
OPERATION
HOURS
Displays the total number of hours that the drum has rotated with tape threaded.H02 DRUM RUNNING
HOURS
Displays the total number of hours that the VTR has been in playback, fast-forwarding,
rewinding, jog, shuttle, variable speed, and edit modes. (Does not include still mode.)
H03 TAPE RUNNING
HOURS
H04 THREADING
COUNTER
Displays the total number of threadings and unthreadings.
Displays the total number of hours that the drum has run with tape threaded since last
reset. Use this information as a guide for head-drum replacements.
For details, refer to the Maintenance Manual Part 1.
H12 DRUM RUNNING
HOURS
(resettable)
H13 TAPE RUNNING
HOURS
(resettable)
Displays the total number of hours that the VTR has been in playback, jog, shuttle and
variable speed modes since last reset. (Does not include stop and still modes.) Use
this information as a guide for replacing the fixed head and pinch rollers.
For details, refer to the Maintenance Manual Part 1.
THREADING
COUNTER
(resettable)
Displays the total number of threadings and unthreadings since last reset.
For details, refer to the Maintenance Manual Part 1.
H14
Function
