A-12 Appendix
Appendix
Error Messages and Warning Messages
Clearing warning messages
1 Press the ALT/[F8] (CANCEL EDIT) button.
2 Select the message to be cleared using the G and
g buttons.
3 Press the [F2] (MARK) button.
An asterisk “*” will appear in front of the
message.
The message will not be displayed or saved.
Cancelling removal
To cancel the removal of a warning message, press the
[F2] (MARK) button.
Adjusting the clock
Press the ALT/[F9] (REAL TIME) button in the error
log menu and use the setting below.
Get current time codes
Hold down the SFT button and press the [F5] (GET
TC) button.
Setting the data and time
Hold down the SFT button and press the [F6] (SET)
button.
Use the f and F buttons to move the bar to the
location to be adjusted.
Use the numeric keys to change the value.
Adjusting minutes and second to zero
Hold down the SFT button and press [F8] (ZERO)
button.
Selecting daylight saving time and normal
time
Hold down the SFT button and press [F9] (SEASON)
button.
STANDARD: normal time
SUMMER: daylight saving time (one hour ahead of
normal time)
Note
Changing between normal and daylight saving times
changes the current time by one hour.
Even if the change crosses midnight, the current date is
not changed.
