Appendix A-11
Appendix
ERROR LOG
1.00:00:00:00 (E) A3
CH.COND
DIAGNOSTICS
TOTAL 03
PAGE
END
PAGE
TOP
ALL
CLEAR
TC
WARNI-
NG
ERROR
TIME
FULL
MSG
CONDI-
TION
EXIT
'97/03/06 10:32:23
TCR 00:00:01:05
SYS NOV RAM CHECK SUM ERR...
2.23:59:59:09 (C) 0B
VIDEO DATA ERROR
3.23:59:59:09 (C) 0F
AUDIO DATA ERROR
Button Display Function Setting
[F1] PAGE TOP Move to the top page on, off
[F2] PAGE END Move to the last page on, off
[F3] FULL MSG Display in full the message selected with the cursor on, off
[F5] WARNING Display warning messages on, off
[F6] ERROR Display error messages on, off
[F7] CONDITION Display condition messages on, off
[F9] TIME Toggle between time code are real time display TC, REAL
[F10] EXIT Return to display of maintenance information
SFT/[F4] ALL CLEAR Clear messages (LOG DATA)
ALT/[F8] CANCEL EDIT Display the CANCEL EDIT screen
ALT/[F9] REAL TIME Display the REAL TIME screen
Error Log Menu
The time and time codes of errors and warnings
occurring during operation can be displayed in a list
form in the display. (Maximum listing is 99 items.)
Openig the error log menu
Use the tip of a narrow object to press the
MAINTENANCE switch and press the [F2] (ERR
LOG) button.
Error Log Menu
For more information about error log menu settings, refer to the Maintenance Manual.
