Appendix A-5
Appendix
Accessories supplied
AC power cord (1)
RCC-5G 9-pin remote control cable (1)
PSW 4 × 16 screws for rack mounting (4)
SRAM 64 KB Memory card (1)
Operation Manual (1)
Maintenance Manual Part 1 (1)
Optional accessories
HKDV-501A HD-SD Cconverter Board
HKDV-502 HD Line Converter Board
HKDV-503 HD Digital Video Controller
HKDV-506A SDTI Board
HKDV-507/507D HD Pull Down Board
BKDW-509 Parallel (50-pin) Interface Kit
RMM-110 Rack Mount Adaptor
BCT-HD12CL Cleaning Cassette
MLB-1B-100 Memory Label
Recommended accessories
For details about recommended accessories, contact
your Sony service representative.
Parallel/serial converter
HD-694 equivalent from ASTRO DESIGN
Corporation
XLR/BNC adaptors
BCJ-XP-TRA equivalent from CANARE Corporation
Design and specifications are subject to change
without notice.
