A-4 Appendix
Appendix
Output connectors
HD SDI OUTPUT
BNC (4, MONITOR with
superimposed text)
1, 2, 3 and MONITOR
SDI (1.485 Gbps) (conforms to
SMPTE 292M/BTA-S004B)
D CONV. SDI OUT (OPTION)
(when the optional HKDV-501A
is installed, D1/D2 switchable)
BNC (3, 3(SUPER) with
superimposed text)
1, 2 and 3(SUPER)
D1 SDI (270 Mbps) (conforms to
SMPTE 259M/CCIR-656-III)
D2 SDI (143 Mbps) (conforms to
SMPTE 259M/CCIR-656-III)
D CONV. OUT (OPTION)
(when the optional HKDV-501A is
installed)
BNC (2, COMPOSITE (SUPER)
with superimposed text)
COMPOSITE (SUPER)
1.0 Vp-p, 75 Ω , sync negative
SYNC Black burst
0.286 Vp-p, 75 Ω , sync negative
SDTI (OPTION) OUT
(when the optional HKDV-506A is
installed)
BNC (1)
SDTI (270 Mbps)
PULL DOWN OUT (OPTION)
(when the optional HKDV-507/
507D is installed)
BNC (2, with superimposed text)
REF. OUT
BNC (2)
1125 SYNC Trilevel SYNC
0.6 Vp-p, 75 Ω , sync negative
AUDIO OUTPUT (AES/EBU)
BNC (2)
CH1/2 and CH3/4
AES/EBU format, unbalanced
AUDIO OUTPUT
XLR 3-pin, male (5)
CH1, CH2, CH3, CH4 and CUE
+4 dBm, (with 600 Ω load), low
impedance, balanced
MONITOR OUTPUT
XLR, 3-pin, female (2)
L and R +4 dBm (with a 600 Ω load), low
impedance, balanced
TIME CODE OUT
XLR, 3-pin, male (1)
2.2 Vp-p, low impedance, balanced
PHONES
JM-60 stereo phone jack
–∞ to –12 dBu (with an 8 Ω load),
unbalanced
Remote connectors
CONTROL PANEL
D-sub 15-pin, female
REMOTE 1-IN D-sub 9-pin, female
REMOTE 1-OUT D-sub 9-pin, female
RS-232C D-sub 25-pin, female
VIDEO CONTROL
D-sub 9-pin, female (for optional
HKDV-503)
PARALLEL I/O (50P)
D-sub 50-pin, female (with
optional BKDW-509)
Specifications
..........................................................................................................................................................................................................
Note
The ANALOG AUDIO INPUT CH1/2/3/4/CUE connectors,
ANALOG AUDIO OUTPUT CH1/2/3/4/CUE connectors,
and TIME CODE IN/OUT connectors (XLR 3-pin) have
gender conventions for input and output connectors in Japan
which are opposite to those everywhere else in the world. If
using this unit with non-Japanese specification equipment,
use male/female adaptors.
