A-2 Appendix
Appendix
Specifications
General
Record format HDCAM
Power requirements
100 to 240 V AC ±10%, 50/60 Hz
Power consumption
230 W
Peak inrush current
(1) Power ON, current probe method: 50 A (240 V),
14 A (100V)
(2) Hot switching inrush current, measured in
accordance with European
standard EN55103-1: 10 A
(230V)
Operating temperature
+5°C to +40°C (+41°F to + 104°F)
Storage temperature
–20°C to +60°C (–4°F to + 140°F)
Humidity 25% to 80% (relative humidity)
Mass 35 kg
Dimensions 427 × 237 × 520 mm (w/h/d)
(16
3
/4 × 9
3
/8 × 20
1
/2 inches)
Tape system
Tape speed 77.4 mm/s (with the frame
frequency of 24Hz)
80.7mm/s (with the frame
frequency of 25Hz)
96.7mm/s (with the frame
frequency of 30Hz)
Digital record/playback time (Using L-size cassette)
155 minutes (with the frame
frequency of 24Hz)
149 minutes (with the frame
frequency of 25Hz)
124 minutes (with the frame
frequency of 30Hz)
Fast forward/rewind time
Approx. 3 minutes (Using L-size
cassettes)
Search speed Shuttle mode:
Still to approx. ±60 times normal
playback speed (with the frame
frequency of 24Hz)
Still to approx. ±58 times normal
playback speed (with the frame
frequency of 25Hz)
Still to approx. ±50 times normal
playback speed (with the frame
frequency of 30Hz)
Variable mode:
–1 to +2 times normal playback
speed
Jog mode:
Still to ±2 times normal playback
speed
Dynamic Tracking range
–1 to +2 times normal playback
speed
Load/unload time 6 seconds or less
Recommended tapes
HDCAM cassette (S- and L-sizes)
Digital video system
Digital video signal format
Sampling frequency
Y: 74.25 MHz
P
B/PR: 37.125 MHz
Quantization 10 bits/sample (Compression:
8 bits/sample)
Compression Coefficient recording system
Channel coding S-NRZI PR-IV
Error correction Reed-Solomon code
Error concealment Adaptive three dimensional
Analog composite output (with optional HKDV-
501A)
Bandwidth Y: 0 to 5.75 MHz +0.5 dB/–3.0 dB
S/N ratio 56 dB or more
Y/C delay 15 ns or less
K factor (2T Pulse)
1% or less
Output SCH phase
Based upon RS-170A/CCIR
R.624-3
