Chapter 4 Menu Settings 4-61
Chapter 4 Menu Settings
VTR BANK
SET UP menu display
4-7 SET UP Menu
To activate the SET UP menu
Press the SET UP button.
To change the SET UP menu page
Press the ALT button.
“$” indicates that more than one menu page exists.
In the SET UP menu, you can store and recall menu
settings to and from the VTR memory banks and
memory card, register items to the PF menu, and set
items in the VTR SETUP menu and PANEL SETUP
menu.
For details on storing and recalling data to or from the VTR
memory banks or memory card, and registering items to the
PF menus, see Section 4-1, “Registering and Storing Menu
Settings” on page 4-1.
SET UP menu
Button
[F1]
Indication
Settings
See Section 4-1-4, “VTR Memory Bank Function” on page 4-4.
[F2]
MEMORY CARD
See Section 4-1-5, “Memory Card Function” on page 4-6.
[F8]
[F9]
REMOTE 9-PIN
REMOTE 50-PIN
on, off
on, off
[F4] PF1&2 ASSIGN
[F5]
PANEL SETUP
VTR SETUP
[F6]
Selects remote operation using a device (optional BKDW-509)
connected to the PARALLEL I/O(50P) connector.
Selects remote operation through a device connected to the REMOTE1-
IN(9P)/OUT(9P) connectors.
See Section 4-1-3, “Registering Items to the PF1/2 Menus” on page 4-3.
See Section 4-7-2, “PANEL SETUP Menu” on page 4-63.
See Section 4-7-1, “VTR SETUP Menu” on page 4-61.
Function
[F1]
[F6]
[F5]
[F4]
[F2]
CH.COND
SETUP
VTR BÅNK: Copy data between
current setup and 8 banks.
MEMORY CÅRD: Copy data
between VTR and memory card.
PF1&2 ÅSSIGN: Åssign PF1/PF2
menu function keys.
PÅNEL SETUP: Panel setting
VTR SETUP: VTR current setup
MEMORY
CÅRD
VTR
BÅNK
PF1&2
ÅSSIGN
off off
PÅNEL
SETUP
VTR
SETUP
REMOTE
9-PIN
REMOTE
50-PIN
REMAIN-T
