User's Guide Part 2

308
Data Display/Edit/Management
[microSD mode]:
Read and write data from/to the microSD memory
card.
[MTP mode]:
Transfer music data (WMA file) from a PC to the
microSD memory card.
2
Select [microSD mode] and press .
The microSD mode is set and “ ” changes to “ ”.
On the PC, “
リムーバブルディスク
” is displayed
for the microSD memory card.
ˎ
You can check the current USB mode and
connection status by the following icons.
Icon Mode/Connection status
Communication mode
microSD mode
MTP mode (Connected)
MTP mode (Transferring)
MTP mode (Completed)
MTP mode (Error)
※
※
It appears when the FOMA terminal is
connected to a PC by the MTP mode and
cannot start the connection because there
is not enough memory. End the unused
applications, increase memory space, and
then retry the operation again.
3
Connect the FOMA terminal and PC
using the FOMA USB Cable with Charge
Function 01/02 (optional).
3
2
1
USB
connector
Insert the connec-
tor horizontally
with the label side
facing up.
External connection
connector
FOMA USB Cable with Charge
Function 01/02 (optional)
USB terminal
External
connection terminal
The icon “ ” (USB cable
cncted) appears in the
stand-by display.
When you press (Link)
and then select “ ”, the
USB mode setting display
appears.
●
Do not format the microSD memory card using
a PC, etc. Make sure to format it on the FOMA
terminal.
●
Even if you set the USB mode setting to
[MTP mode] or [microSD mode] and connect
the FOMA terminal to a PC, the PC may not
recognize the FOMA terminal while the FOMA
terminal is accessing to the microSD memory
card (reading/saving data, etc.) or the microSD
memory card is not inserted.
●
While the USB mode setting is set to [MTP mode]
and the FOMA terminal is connected to a PC,
when you press , the Standard menu appears.
The Kisekae menu is not displayed. Also, some
functions may be limited.
●
For more details about the USB mode setting,
see the website below.

http://www.SonyEricsson.co.jp/so906i/faq.html
Terminating the microSD Mode
To remove the FOMA terminal from a PC,
perform the procedure to safely remove the
hardware on the PC in advance, which is
slightly different for each OS.
Example: When using Windows XP
1
Double-click the task tray icon [ ]
（ハードウェアの安全な取り外し）
on the
Windows desktop.
