= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Congratulations on your purchase of the Sony Ericsson Z558i. In addition to the pre-installed Z558i multimedia content, you have more waiting for you at www.sonyericsson.com/fun. If you register at www.sonyericsson.com/register, you get an exclusive offer. Don’t miss out. Go there now.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Added dimensions – Accessories from Sony Ericsson Stereo Portable Handsfree HPM-70 Deep bass with light in-ear design. Desk Stand CDS-60 Your phone’s best assistant: connect a USB cable, charger and portable handsfree. Bluetooth™ Headset HPB-PV705 A powerful Bluetooth™ headset with compact design.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Contents Getting started ................... 4 Getting to know the phone ............................ 7 Entering characters .......... 12 Calling ............................... 19 Messaging ........................ 31 Imaging ............................. 36 Entertainment ................... 40 Connectivity ...................... 44 More features ................... 50 Troubleshooting ...............
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Your mobile phone has the capability to download, store and forward additional content, e.g. ringtones. The use of such content may be restricted or prohibited by rights of third parties, including but not limited to restriction under applicable copyright laws. You, and not Sony Ericsson, are entirely responsible for additional content that you download to or forward from your mobile phone.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 3 Restricted Rights: Use, duplication or disclosure by the United States government is subject to the restrictions as set forth in the Rights in Technical Data and Computer Software Clauses in DFARS 252.227-7013(c) (1) (ii) and FAR 52.227-19(c) (2) as applicable. Part of the software in this product is copyright © SyncML initiative Ltd. (1999-2002). All rights reserved.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Getting started To insert the SIM card 1 Remove the battery cover. 2 Slide the SIM card into its holder with the gold contacts facing down. 3 Insert the battery with the label side up and the connectors facing in. 4 Slide the battery cover into place. 4 Getting started To charge the battery 1 Connect the charger plug to the phone with the symbol facing upwards. 2 It may take 30 minutes before the battery icon appears.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Talk time or standby time may become shorter due to wear and you may have to replace your battery. Only use approved batteries from Sony Ericsson % 61 Battery. Save contacts to your SIM card before you remove it from another phone. Contacts may have been saved in the phone memory % 20 Contacts. To turn the phone on and off 4 } Yes if you want the setup wizard to help you with instructions and tips.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 To insert and remove the memory card PIN You may need a PIN (Personal Identification Number) from your network operator to activate the services in your phone. Each PIN digit appears as *, unless it starts with emergency number digits, for example, 112 or 911. This is so you can always make emergency calls. % 20 Emergency calls. Press to correct mistakes.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Getting to know the phone Phone overview 7 14 8 1 1 Camera key 2 Selection key 3 Back key 4 "Memory Stick Micro" ("M2") slot 5 Activity menu key 6 Microphone 7 Ear speaker 8 Navigation key 9 Volume button 9 10 Selection key 2 10 11 Clear key 3 11 12 On/off key 13 Charger and USB connector 14 stylus 4 5 6 12 13 Getting to know the phone 7
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Menu overview PlayNow™* Internet Services* Entertainment Online services* Games VideoDJ™ PhotoDJ™ MusicDJ™ Remote control Record sound Demo tour Camera Messaging Media player Write new Inbox My friends* Email Call voicemail Drafts Outbox Sent messages Saved messages Templates Settings File manager*** All files On Memory Stick In phone 8 Contacts** Options New contact Getting to know the phone Radio
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Organizer Calls*** All Answered Dialled Missed Alarms Calendar Tasks Notes Calculator Synchronization Timer Stopwatch Applications Code memo Settings*** General Sounds & alerts Display Calls Connectivity* * Some menus are operator-, network- and subscription-dependent. ** Options when phone contacts are set to default. Options change when SIM contacts are set to default.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Navigating the menus The main menus are shown as icons. Some submenus include tabs that appear on the screen. To edit a standby shortcut 3 From standby, select Menu } Settings } General } Shortcuts and select a shortcut } Edit. 4 Scroll to a function } Shortcut. Activity menu Use the activity menu to view and handle new events, and access bookmarks and shortcuts. • Press to go to the main menu or to select items.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Shut down menu Use the shut down menu to turn off the phone, activate silent mode or activate a profile. For more information about profiles % 50 Profiles. To open the shut down menu Press and select a menu item. File manager Files such as pictures, videos, sounds, themes, games and applications are saved in folders in the phone memory. If you have inserted a memory card you can save the files on it.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 To format the memory card From standby, select Menu } File manager } More } Format M.S. } Yes and enter your phone lock code. For more information % 54 Phone lock. Entering characters Transferring files For more information % 49 Transferring files. Handwriting recognition Languages Select the language to use in the phone menus or when writing text.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Candidate and predictive characters As you write, candidate characters appear. Select one or accept the one that appears on the screen. After you select a candidate character, predictive characters may appear. Select one from the predictive characters or write your own.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Writing numbers Write numbers from the dotted ends as shown below. • • • • To calibrate the screen 1 From standby, select Menu } Messaging } Write new } More } Handwriting calib.. 2 Follow the instruction to calibrate the screen. Text input To enter text by using the keypad, press the key you want directly.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 To enter letters using T9 Text Input 1 For example, if you want to write the word “Jane”, press , , , . 2 If the word shown is not the one you want, press or repeatedly to view alternative words. To accept and add a space, press . To accept a word without adding a space, press . 3 Continue writing your message. To enter punctuation marks, press and then or repeatedly.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 General instructions Regardless of which input method you choose, your phone can speed up the input of Chinese characters. Whenever you enter a stroke or a Pinyin letter, a candidate row of the most frequently used characters containing that stroke or relating to that letter appear at the bottom of the screen. If the character you want is not displayed in the candidate row, press to view another candidate row.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Number Stroke Basic Key Category Stroke Stroke Name Character 㸷 ҹ 佁 ᬊ 䭓 Right Slope- ៥ ⇥ ៤ Ӥ Hook Down-Over- ᖗ ᖙ ᗱ ᖬ Hook Down-Over- ⬉ г ↯ ܘᄨ CurvedHook Down-Over- ϧ Ӵ 䕀 Left Slope Down-Over- 偀 Ϣ ᓴ Down-Hook ো 䌍 Down-Over- 哢 哤 Down ݭᄫ Ⲃ Over-Hook 䗮 ܡ Over-Down ষ Ꮖ ᠋ к 偼 Over-Down- д г ৠ ∌ Hook Down-Lift OverLeft Slope জ П ⱏ ⼒ Over-Down- ঞ ᵕ ᓋ ᓎ OverLeft Slope 䰓 䯳 䰜 OverLeft Slope- 䙷 䚼 CurvedHook Number Strok
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 For example, to enter “ ֵᙃ ” 1 Enter “ ”, “ ” and “ ”. 2 Move the cursor to “ ֵ ”, press 3 Move the cursor to “ ᙃ ”, press again to select “ ᙃ ”. Number Key mno . Example of using the wild card key The wild card key , is used to supplement unclear strokes in entering characters.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Calling Making and receiving calls Turn on the phone and make sure that you are within range of a network % 5 To turn the phone on and off. If your subscription includes the Calling Line Identification service and the caller’s number is identified, the number is displayed. If the number is saved in Contacts, the name, number, and picture are displayed. If the number is a restricted number, Withheld is displayed.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 To add a call list number to contacts 1 From standby, select } Calls and select a tab. Scroll to the number you want to add } More } Save number. 2 Select a contact to add the number to or } New contact. Emergency calls Your phone supports international emergency numbers such as 112 and 911. Use them to make an emergency call in any country, with or without a SIM card in the phone, if a GSM network is in range.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 To add a picture or a ringtone to a contact 1 From standby, select Menu } Contacts and select the contact } More } Edit contact. 2 Select the relevant tab, then } Picture or Ringtone } Add. Select a file and } Save. To set the default number for a contact 1 To set the phone number to be displayed first for a contact, from standby, select Menu } Contacts and scroll to the contact. 2 } More } Default number and select a number.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 To call contacts written in Latin characters 1 From standby, select Menu } Contacts. Press and hold to switch the search language to English. 2 Enter the first letter of the contact you want to call. 3 When the contact is highlighted, press or to select a number } Call. To call a SIM contact • If SIM contacts is default, from standby, select Menu } Contacts and select a name and number from the list } Call.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 To send contacts • To send a selected contact } More } Send contact and select a transfer method. • To send all contact, from standby, select Menu } Contacts } Options } Advanced } Send all contacts. To edit a phone contact 1 From standby, select Menu } Contacts and select a contact } More } Edit contact. 2 Select a tab and edit the information } Save.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Voicemail Before voice dialling Activate the voice dialling function and record your voice commands. An icon appears next to a phone number that has a voice command. If your subscription includes an answering service, callers can leave a voice message when you cannot answer a call. To enter your voicemail number Press and hold } Yes enter the number } OK. You get the number from your service provider.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 The magic word Caller name Hear your recorded contact name when you receive a call from that contact. Record and use a voice command as a magic word to activate voice control without pressing any keys. The magic word can only be used with a handsfree. To turn the caller name on or off From standby, select Menu } Settings } General } Voice control } Play caller name.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 1 2 3 4 5 6 To activate voice answering and record voice answer commands From standby, select Menu } Settings } General } Voice control } Voice answer } Activate. Instructions appear. } Continue. Wait for the tone and say “Answer”, or another word. } Yes to accept or } No for a new recording. Instructions appear } Continue. Wait for the tone and say “Busy”, or another word. } Yes to accept or } No for a new recording.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 To check all divert options From standby, select Menu } Settings } Calls } Divert calls } Check all. More than one call Handle more than one call simultaneously. Call waiting service When call waiting service is activated, you hear a beep if you receive a second call. To activate the call waiting service From standby, select Menu } Settings } Calls } Manage calls } Call waiting } Activate.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Conference calls Start a conference call by joining an ongoing call and a call on hold. You can then put the conference on hold and add up to five participants, or can make another call. To join the two calls into a conference call } More } Join calls. To add a new participant 1 } More } Hold to put the joined calls on hold. 2 } More } Add call and call the next person. 3 } More } Join calls.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Accept calls Only receive calls from certain phone numbers. If the divert calls option When busy is activated, calls are diverted. To add numbers to the accepted callers list 1 From standby, select Menu } Settings } Calls } Manage calls } Accept calls } Only from list } Edit } Add. 2 Select a contact or } Groups. For more information on groups % 30 Groups.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Additional calling functions Groups Tone signals Use telephone banking services or control an answering machine with tone signals during a call. Create a group of numbers and email addresses to send messages to several recipients at the same time % 31 Messaging. To use tone signals • Press , or to send tones. • } More } Disable tones or Enable tones to turn the tones on or off during a call. • Press to clear the screen after a call.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Closed user groups If your network supports closed user groups, you may be able to call at lower costs. You can save up to ten groups. An index number is required from your network operator. To add a group From standby, select Menu } Settings } Calls } Manage calls } Closed groups } Edit list } New group } Add. Enter the name of the user group } Continue. Enter the index number } Save.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 2 If there is no number shown } New ServiceCentre and enter the number, including the international “+” sign and country code } Save. To write and send a text message 1 From standby, select Menu } Messaging } Write new } Text message. 2 Write your message. To insert an item in your message } More } Add item. 3 } Continue. (To save in Drafts press and } Yes.) 4 } Enter phone no. or Contacts lookup to enter a recipient.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 To delete messages • To delete a selected message, press . • To delete several messages in a folder } More } Delete all msgs or Mark several. When marking several messages } Mark to select messages. } More } Delete messages. Long messages The number of characters allowed in a text message depends on the writing language. You can send a longer message by linking two or more messages.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 4 To send, follow the instructions for text messages % 32 To write and send a text message. You have the same options for picture messages as for text messages % 31 Text messaging (SMS). To create your own signature for picture messages 1 From standby, select Menu } Messaging } Settings } Picture message. 2 } Signature } New signature and create your signature as a picture message.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Receiving voice messages When you receive a voice message, it appears in the activity menu or as a popup % 10 Activity menu. Press to close the message. Email Connect to a POP3 or IMAP4 mail server to send and receive email messages with your phone. You can use the same email settings in your phone as in your computer email program. With a POP3 email account, messages are downloaded to each computer or device used for access.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 To save an item or attachment in an email message • To save an email address, a phone number or a Web address, select the item } More and select to save the item. • To save an attachment, select the message } More } Attachments. Select the attachment } More and select an option. To delete email messages • To delete a selected message, press . • To delete several messages in a folder } More } Mark several. } Mark to select messages.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 3 } Capture to take a picture. } Record to start a video recording. If you try to record a strong light source such as direct sunlight or a lamp, the screen may black out or the picture may be distorted. To use the zoom Press and to zoom in and zoom out. To adjust brightness Use the volume button to increase or decrease brightness. Camera options When the camera is activated } More to view options: • View all pictures.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Saving and sending pictures and video clips The picture or the recorded video clip is saved in the phone memory or on the memory card. You can send the picture or video clip in a picture message. To exchange pictures and video clips using other transfer methods % 38 Exchanging pictures and video clips. Pictures and video clips All pictures and video clips are saved in File manager.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 To receive and save a picture or video clip From a message containing the picture or video clip % 31 Messaging. If you want to receive a picture or a video clip via another transfer method, make sure the transfer method is activated and follow the instructions that appear. Screen saver and wallpaper If you have a picture as wallpaper, this picture is shown in standby mode.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Entertainment Media player Play music and video clips that you download or receive in a picture message or transfer from your computer. The following file types are supported: MP3, MP4, MP4A, 3GP, AAC, AMR, G-MIDI, EMY, IMY and WAV (16 kHz maximum sample rate). Your phone also supports streamed files that are 3GPP compatible. Music and video clips Play music and video clips saved in your phone.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Radio Listen to FM radio with RDS (Radio Data Systems) functionality. You must connect the handsfree to your phone as it works as an antenna. The radio can also be used as an alarm signal % 50 Alarm clock. To listen to the radio 1 Connect the handsfree to your phone 2 From standby, select Menu } Radio. Radio control • } Search to find a broadcasting frequency. • Press or to move 0.1 MHz. • Press or to select preset channels.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Ringtones and melodies Your phone comes with melodies that can be used as ringtones. You can exchange melodies by selecting a transfer method. Please note that you may not be allowed to exchange some copyright-protected material. To set sounds and alerts options From standby, select Menu } Settings } Sounds & alerts, you can set: • Ring volume – select the volume of a ringtone.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Sound recorder Record your own memos or calls which can be set as ringtones. In some countries or states it is required by law that you inform the other person before recording a call. To start a sound recording From standby, select Menu } Entertainment } Record sound. To listen to your recordings 1 } File manager } Sounds and select a recording. 2 } Play to listen to the recording.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 To start and end an application From standby, select Menu } File manager } Applications, select an application } Select. Press and hold to end the application. Unrecognized formats are saved in the Other folder. To download a theme From standby, select Menu } File manager } Themes and scroll to a direct link } Go to. To download a game From standby, select Menu } Entertainment } Games and scroll to a direct link } Go to.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Using Internet Browse the Internet using HTTP (Hyper Text Transfer Protocol). To select an Internet profile From standby, select Menu } Settings } Connectivity } Internet settings } Internet profiles and select a profile to use. To download from the Sony Ericsson Web site 1 From standby, select Menu } Internet Services } More } Go to } Bookmarks,select the Sony Ericsson Web site, } Go to.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Synchronizing Synchronize contacts, appointments, tasks and notes via Bluetooth technology, Internet services or a USB cable. Visit www.sonyericsson.com/support to download the software or Getting started guides for synchronization. Synchronization with nearby devices Install computer synchronization software by downloading it from www.sonyericsson.com/support. The software includes help information.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Bluetooth™ wireless technology Bluetooth wireless technology makes it possible to connect wirelessly to other Bluetooth devices. You can: • connect to several devices at the same time. • synchronize information with other devices. • use remote control functionality. • use a remote screen. • exchange items and play multiplayer games.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 To add a device to your phone 1 From standby, select Menu } Settings } Connectivity } Bluetooth } My devices } New device to search for available devices. 2 Select a device from the list. 3 Enter a passcode, if required. To save power From standby, select Menu } Settings } Connectivity } Bluetooth } Powersave } On. This reduces power consumption when using a single Bluetooth device. Turn it off when using several Bluetooth devices.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Transferring files Update service You can transfer pictures, videos, sounds, and themes by using Bluetooth wireless technology or a USB cable. Download and install new software without affecting the user data in your phone. Update your phone over the air or online via USB cable and an Internet-connected computer. You can also send files via email % 35 Email or picture messages % 33 Picture messaging (MMS).
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 More features Time and date Time and date are always displayed in standby. To set the time and date From standby, select Menu } Settings } General } Time & date: • • • • Time – edit time and time format. Date – edit date and date format. Time zone – select a time zone. Daylight saving – turn daylight saving on and off. • Auto time zone – switches time zone automatically.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Calendar Add, save, edit and set reminders for appointments. Synchronize the calendar with a Web calendar or a computer calendar % 46 Synchronizing. To add a new appointment From standby, select Menu } Organizer } Calendar select a date } New appointment } Add. Enter details } Continue to confirm each entry. } Select to confirm the appointment. To view an appointment From standby, select Menu } Organizer } Calendar and select a day.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 To send an appointment 1 From standby, select Menu } Organizer } Calendar and select an appointment. 2 } More } Send and select a transfer method. To send a task 1 From standby, select Menu } Organizer } Tasks and select a task. 2 } More } Send and select a transfer method. Tasks Notes Add new tasks or use existing tasks as templates. You can also set reminders for tasks. Make notes and save them in a list.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 SIM card lock The SIM card lock protects your subscription from unauthorized use. Most SIM cards are locked at the time of purchase. If the SIM card lock is on, you have to enter a PIN every time you turn on your phone. If you enter your PIN incorrectly three times in a row, the SIM card is blocked and the message PIN blocked is displayed. To unblock it, you need to enter your PUK (Personal Unblocking Key).
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Phone lock Code memo The phone lock protects the phone against unauthorized use. You can change the phone lock code (0000) to any four- to eight-digit personal code. Save security codes, such as for credit cards, in the code memo. Set a passcode to open the code memo. Enter a checkword. When you enter your passcode to open the code memo, the checkword is shown for a short time. If the passcode is correct, the correct codes are shown.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 To add a new code 1 From standby, select Menu } Organizer } Code memo and enter your passcode } Continue } New code } Add. 2 Enter a name associated with the code, for example, the name of the credit card company } Continue. 3 Enter the code } Done. To change the passcode 1 From standby, select Menu } Organizer } Code memo and enter your passcode } Continue } More } Change passcode. 2 Enter your new passcode } Continue.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 No indication of charging The battery is empty or has not been used for a long time. It may take up to 30 minutes before the battery icon appears. Error messages The phone cannot be turned on The battery is discharged % 4 To charge the battery. Insert correct SIM card Are you using the correct operator SIM card for your phone? Charging a non Sony Ericsson battery % 61 Battery. Emerg.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 PIN blocked/PIN2 blocked To unblock % 53 SIM card lock. PUK blocked Contact your network operator. Phone locked The phone is locked. To unlock the phone % 54 Phone lock. Phone lock code The phone lock code is required % 54 Phone lock. Important information Sony Ericsson Consumer Web site On www.sonyericsson.com/support there is a support section where help and tips are only a few clicks away.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Country Phone number Australia Argentina Austria Belgium Brazil Canada Central Africa Chile China Colombia Croatia Czech Republic Denmark Finland France Germany Greece 1-300 650 050 questions.AU@support.sonyericsson.com 800-333-7427 questions.AR@support.sonyericsson.com 0810 200245 questions.AT@support.sonyericsson.com 02-7451611 questions.BE@support.sonyericsson.com 4001-0444 questions.BR@support.sonyericsson.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Singapore Slovakia South Africa Spain Sweden Switzerland Taiwan Thailand Turkey Ukraine United Arab Emirates United Kingdom United States Venezuela 67440733 02-5443 6443 0861 632222 902 180 576 013-24 45 00 0848 824 040 02-25625511 02-2483030 0212 47 37 777 (+380) 44 590 1515 43 919880 08705 23 7237 1-866-766-9374 0-800-100-2250 questions.SG@support.sonyericsson.com questions.SK@support.sonyericsson.com questions.ZA@support.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Guidelines for Safe and Efficient Use Please read this information before using your mobile phone. These instructions are intended for your safety. Please follow these guidelines. If the product has been subject to any of the conditions listed below or you have any doubt as to its proper function make sure you have the product checked by a certified service partner before charging or using it.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Battery Driving We recommend that you fully charge the battery before you use your mobile phone for the first time. A new battery or one that has not been used for a long time could have reduced capacity the first few times it is used. The battery should only be charged in temperatures between +5°C (+41°F) and +45°C (+113°F). Use only Sony Ericsson branded original batteries intended for use with your mobile phone.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Radio frequency (RF) exposure and SAR Your mobile phone is a low-power radio transmitter and receiver. When it is turned on, it emits low levels of radio frequency energy (also known as radio waves or radio frequency fields). Governments around the world have adopted comprehensive international safety guidelines, developed by scientific organizations, e.g.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Disposal of old electrical & electronic equipment This symbol indicates that all electrical and electronic equipment included shall not be treated as household waste. Instead it shall be left at the appropriate collection point for recycling of electrical and electronic equipment.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Limited Warranty Sony Ericsson Mobile Communications AB, S-221 88 Lund, Sweden, (Sony Ericsson), provides this Limited Warranty for your mobile phone and original accessory delivered with your mobile phone (hereinafter referred to as “Product”). Should your Product need warranty service, please return it to the dealer from whom it was purchased, or contact your local Sony Ericsson Call Centre (national rates may apply) or visit www.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 3.This warranty does not cover any failure of the Product due to normal wear and tear, or due to misuse, including but not limited to use in other than the normal and customary manner, in accordance with the Sony Ericsson instructions for use and maintenance of the Product. Nor does this warranty cover any failure of the Product due to accident, software or hardware modification or adjustment, acts of God or damage resulting from liquid.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 *EUROPEAN UNION (EU) Declaration of Conformity If you have purchased your Product in an EU country you can have your Product serviced, under the conditions set out above, within the warranty period in any EU country where an identical Product is sold by an authorised Sony Ericsson distributor. To find out if your Product is sold in the EU country you are in, please call the local Sony Ericsson Call Centre.
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 Index A calls adding personal ringtones ....................... 21 pictures to contacts ..................... 21 adding appointment ............................. 51 alarm clock ........................................... 50 answering service ................................ 24 applications .......................................... 43 appointment adding .......................................... 51 answering ...........................
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 D date ...................................................... 50 declaration of conformity ..................... 66 diverting calls ....................................... 26 download ............................................. 45 Internet ..................................................45 bookmarks ....................................45 K keypad input .........................................14 L E email .........................
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 microphone, off/on ............................... 19 multitap text input ................................ 14 music .................................................... 40 My friends ............................................ 36 N navigation key ...................................... 10 networks ............................................... 19 notes ....................................................
= LB8*B3 $B(1B$VLD ERRN 3DJH )ULGD\ $XJXVW 30 settings email ............................................ 44 Internet ......................................... 44 picture messages ......................... 44 setup wizard ................................... 5 time and date ............................... 50 shortcuts .............................................. 10 show/hide phone ................................. 47 silent mode ..........................................
