Digital 4K Video Camera Recorder/Digital HD Video Camera Recorder FDR-X1000V/HDR-AS200V How to use Read This First Identifying the parts Identifying the parts [1] Screen display Screen display [2] Getting Started Checking the bundled items Checking the bundled items [3] Inserting the battery pack Inserting the battery pack [4] Charging the battery pack Charging the battery pack [5] Inserting a memory card Inserting a memory card [6] The memory cards that can be used with the camera [7]
Using the Tripod Adaptor Using the tripod adaptor (HDR-AS200V only) [8] Using the Waterproof Case Identifying the parts (Waterproof case) [9] Using the waterproof case [10] On waterproof performance of the waterproof case [11] Notes on use for the waterproof case [12] Water leakage [13] Waterproof packing [14] How to check for water leaks [15] Maintenance [16] Using Adhesive Mount Using the adhesive mount [17] Shooting Shooting movies and still images About the REC HOLD (lock) switch [18] Shooting movies
SteadyShot [27] Flip [28] Scene [29] White balance [30] AE shift [31] Color mode [32] Movie format [33] Audio recording setting [34] Wind noise reduction [35] Loop recording time [36] Still image angle of view [37] Still image mode switching [38] Still image shooting interval [39] Self-timer [40] Interval photo recording [41] Camera settings Wi-Fi connection [42] GPS log [43] Airplane mode [44] Mount [45] Time Code/User Bit [46] IR-Remote Control [47] HDMI settings [48] USB Power Supply [49] Auto power off
Viewing images on a TV Viewing images on a TV [59] Deleting images Delete [60] Create your movie Highlight Movie Maker Creating the highlight movie [61] Importing the BGM [62] Mount [63] Stream real-time movie to a movie streaming site Live Streaming with your camera (Real time movie streaming) Live Streaming [64] Preparing for Live Streaming [65] Performing Live Streaming [66] Restrictions [67] Using the camera connected to other devices via Wi-Fi Connecting to your smartphone Preparation for connectin
Connecting a single camera to Handycam (Single connection) [74] Connecting multiple cameras to Handycam (Multi connection) [75] Editing images imported to your computer Using the Action Cam Movie Creator Useful functions of Action Cam Movie Creator [76] Installing Action Cam Movie Creator on your computer [77] Others Recordable time Estimated duration of recording and playback for supplied battery pack [78] Estimated recording time of movies [79] Estimated number of recordable still images [80] Battery p
On operating temperatures [94] On moisture condensation [95] Notes on optional accessories [96] Note on disposal/transfer of the memory card [97] On GPS [98] On GPS errors [99] On GPS use restriction [100] Specifications Specifications [101] Trademarks Trademarks [102] Notes on License On GNU GPL/LGPL applied software [103] Troubleshooting List of Default Setting List of Default Setting List of Default Setting [104] Troubleshooting Troubleshooting Troubleshooting [105] Battery pack and power Cannot t
Battery life is short. [108] Cannot charge the camera. [109] The remaining charge indicator is incorrect. [110] Memory card Operations using the memory card cannot be performed. [111] Shooting images Cannot record images. [112] Cannot insert dates on images. [113] Viewing images Cannot playback images. [114] The image does not appear on the TV. [115] GPS The camera is not receiving a GPS signal. [116] Excessive error in location information.
Warning indicators and messages Warning indicators and error messages Warning indicators and error messages [129] [1] How to use Read This First Identifying the parts FDR-X1000V HDR-AS200V Identifying the parts
1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. 17. 18.
Display icon at 1 : Wi-Fi function enabled : Location information cannot be received because the camera is searching for GPS satellites to receive GPS signals. : Recording location information available while triangulating : Airplane mode enabled : SteadyShot enabled : Memory card is not inserted or cannot record to memory card.
Camera (1) Camera is set in the Waterproof Case. Open the cover of the case as illustrated below.
Attachment Buckle (1) Flat Adhesive Mount (1) Curved Adhesive Mount (1) Tripod adaptor (1) (HDR-AS200V only) Startup Guide (1) Reference Guide (1) [4] How to use Getting Started Inserting the battery pack Inserting the battery pack 1. Slide the lock lever to open the battery pack cover.
HDR-AS200V 2. Insert the battery pack. FDR-X1000V HDR-AS200V ：Align the mark as illustrated. 3. Close the cover. Confirm that the yellow mark on the lock lever is not visible. To remove the battery pack Open the cover and slide the battery ejection lever, then remove the battery pack. To set auto power off function Select [A.OFF] from the [SETUP] - [CONFG] screen, then set the auto power off function. The default setting is [60sec]. Change the setting as necessary. For details, see “Auto power off”.
[5] How to use Getting Started Charging the battery pack Charging the battery pack 1. Turn off the power of the camera. Charging is not possible when the camera is turned on. 2. Open the connector cover, connect the camera to an activated computer with the micro USB cable (supplied). The REC/access/CHG (Charge) lamp lights in amber. FDR-X1000V HDR-AS200V : Connector cover : Micro USB cable : REC/access/CHG (Charge) lamp 3.
Via AC-UD10*2 (sold separately): Approx. 175 minutes *1 Time required to charge a fully depleted battery pack at a temperature of 25°C (77°F). Charging may take longer under certain circumstances or conditions. *2 Rapid charging is possible by using the USB charger AC-UD10 (sold separately). To connect to the charger, use the micro USB cable (supplied). Checking the remaining battery charge A remaining charge indicator appears on the upper right of the display panel.
HDR-AS200V 1: microSD card 2: Memory Stick Micro (Mark2) media : Terminal side : Printed side 3. Close the cover. To eject the memory card Open the cover, then lightly push the memory card once. Note Insert the memory card properly, confirming each side is facing the correct direction. Confirm the direction of the memory card. If you forcibly insert the memory card in the wrong direction, the memory card, memory card slot, or image data may be damaged. Format the memory card before use.
Save important data on the memory card on other media such as a computer, before formatting the memory card. Do not insert anything other than the compliant size of memory card into the memory card slot. Otherwise, a malfunction may result. When inserting or ejecting the memory card, be careful to prevent the memory card from popping out and dropping.
To remove the tripod adaptor Loosen the screw of the tripod adaptor in the direction of the arrow and remove the tripod adaptor from the camera. Note Attach the waterproof case to the camera when using in water.
SPK-AS2 (supplied with HDR-AS200V)
1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. REC HOLD (lock) switch Leash attachment hole REC (Movie/Photo) button/ENTER (Menu execute) button Case body Case cover NEXT (next menu) button PREV (previous menu) button Tripod screw hole Buckle lock Buckle Cord Waterproof packing [10] How to use Getting Started Using the Waterproof Case Using the waterproof case By inserting the camera in the waterproof case, you can shoot movies at a waterfront. 1.
HDR-AS200V (SPK-AS2) 2. Open the case cover. 3. Insert the camera in the case body. Release the REC HOLD (lock) switch on the camera. FDR-X1000V (SPK-X1) HDR-AS200V (SPK-AS2) 4. Insert the tab of the case body into the slot of the case cover.
HDR-AS200V (SPK-AS2) 5. Hook the buckle over the tab on the lower part of the case cover direction of , until it clicks into place. Make sure the buckle is locked by the buckle lock.
Note You cannot operate the REC button when the REC HOLD switch is set to the lock position. Release the lock in the direction of the arrow below, before operation.
Since the camera in the waterproof case fails to focus underwater, it is not suitable to shoot images underwater. You can record audio while the camera is in the waterproof case, but the sound level is reduced. Thread a suitable cord through the leash attachment hole of the waterproof case, then attach the cord to an item you intend to use with the camera.
SPK-X1 (supplied with FDR-X1000V) When using the optional anti-fog sheet (AKA-AF1), place it in the gap on the opposite side of the camera display. : Anti-fog sheet SPK-AS2 (supplied with HDR-AS200V) When using the optional anti-fog sheet (AKA-AF1), place it in the gap on the bottom of the camera. : Anti-fog sheet [12] How to use Getting Started Using the Waterproof Case Notes on use for the waterproof case Do not throw the waterproof case into the water.
When the camera overheats, it may be automatically turned off or recording may malfunction. To use the camera again, leave it in the cool place for a while to cool down. If sun oil is on the waterproof case, be sure to wash it off thoroughly using lukewarm water. If the waterproof case is left with sun oil on its body, the surface of the waterproof case may become discolored or damaged (such as cracks on the surface).
[16] How to use Getting Started Using the Waterproof Case Maintenance After recording in a location with a sea breeze, wash this unit thoroughly in fresh water with the buckle fastened to remove salt and sand, then wipe with a soft dry cloth. It is recommended that you submerge the waterproof case in fresh water for about 30 minutes. If it is left with salt on it, metal portions may be damaged or rust may form and cause water leakage.
3. Remove dust, moisture and oily substances completely from the surface where the adhesive mount is to be attached. 4. Peel off the release paper on the back, and fix the adhesive mount in the desired location. Adhesive power reaches its maximum strength 24 hours after the adhesive mount is attached to the desired location. To attach to or detach from the attachment buckle Press and hold the circled part to unlock, then slide it in the opposite direction of step 2.
The REC HOLD (lock) switch can prevent accidental operation. Slide the REC HOLD (lock) switch in the HOLD direction to lock the REC button. To release the lock, slide it in the opposite direction. Before recording, release the lock. If you lock the camera while recording, the recording state will be kept *. If you lock the camera after you stop recording, the stopped state will be kept *. * Release the lock to change the setting. FDR-X1000V HDR-AS200V 1. REC HOLD (lock) switch 2. REC button 3.
To stop shooting Press the REC button during shooting. Hint If you set the mount setting before creating a highlight movie, the number of highlight scene in the movie will increase. [20] How to use Shooting Shooting movies and still images Shooting still images (Photo mode) Record still images. 1. Press the NEXT button or PREV button to turn on the power. 2. Press the NEXT button or PREV button to display [PHOTO]. 3. Press the REC button to shoot.
Formatting a memory card may improve the recording conditions. Also, you may minimize bad effects of the data fragmentation by formatting a memory card in advance to increase the free space of memory. [22] How to use Shooting Shooting movies and still images Interval photo recording mode The camera records still images at regular intervals until you stop shooting. 1. Press the NEXT button or PREV button to turn on the power. 2. Press the NEXT button or PREV button to display [INTVL]. 3.
INTVL: Interval photo recording mode LIVE: Live streaming mode SETUP: Setup mode PLAY: Play mode PwOFF: Power off Items you can set in SETUP (Setup mode) VMODE: Image quality setting V.FMT: Movie format STEDY: SteadyShot AUDIO: Audio recording WIND: Wind noise reduction COLOR: Color mode L.
FDR-X1000V HDR-AS200V You can set items using the following 3 buttons on the camera. : REC/ENTER button Executes the menu : PREV button Goes to the previous menu : NEXT button Goes to the next menu 1. Press the NEXT button or PREV button to turn on the power. To power off, press the NEXT button or PREV button to display [PwOFF] and press the ENTER button. 2. Press the NEXT button or PREV button to display [SETUP], then press the ENTER button. 3.
that can be set depend on the [V.FMT] setting. 1. Press the NEXT button or PREV button to select [SETUP] - [VMODE], then press the ENTER button. 2. Press the NEXT button or PREV button to select the following settings, then press the ENTER button. When [V.
Playback frame rate *1 : 240p/200p *3 When [V.FMT] is set to [HD] (recording in XAVC S) 1080 60p 50 M Recorded image: XAVC S 50 Mbps Resolution: 1920×1080 Imaging frame rate *1 : 60p/50p Playback frame rate *1 : 60p/50p 1080 30p 50 M Recorded image: XAVC S 50 Mbps Resolution: 1920×1080 Imaging frame rate *1 : 30p/25p Playback frame rate *1 : 30p/25p 1080 24p 50 M (only when [V.
1080 120p 100 M (FDR-X1000V only) Recorded image: XAVC S 100 Mbps High speed recording Resolution: 1920×1080 *2,*4 Imaging frame rate *1 : 120p/100p Playback frame rate *1 : 120p/100p *3 1080 120p 60 M (FDR-X1000V only) Recorded image: XAVC S 60 Mbps High speed recording Resolution: 1920×1080 *2,*4 Imaging frame rate *1 : 120p/100p Playback frame rate *1 : 120p/100p *3 When [V.
2160 24p 60 M (only when [V.SYS] is set to [NTSC]) Recorded image: XAVC S 60 Mbps*4 Resolution: 3840×2160 Imaging frame rate: 24p Playback frame rate: 24p BACK: Returns to the [VMODE] menu. *1 Frame rate depends on the NTSC/PAL setting. *2 Action Cam Movie Creator™ converts the frame rate to 60p/50p and plays back images at standard speed. It also allows you to play back images in slow motion and edit them during slow motion playback.
Note The field angle is 120° at the default setting. For a wider field angle, set [STEDY] to [OFF]. The field angle changes when the image quality setting is set to the 4K quality or the high speed recording quality. SteadyShot is not effective in the following settings.
2. Press the NEXT button or PREV button to select the following setting, then press the ENTER button. NORML: Shoots images in the standard quality. WATER: Shoots images in an image quality suitable for underwater shooting. BACK: Returns to the [SCENE] menu. Note If you select [WATER], you cannot set the white balance. Dive Door (AKA-DDX1(sold separately)) is required for underwater shooting. (FDR-X1000V only) Underwater Housing (MPK-AS3(sold separately)) is required for underwater shooting.
C.SET: Acquires the base white color for shooting under the light source. Place a white reference object under the same lighting conditions as the subject and press the REC/ENTER button. BACK: Returns to the [WB] menu. Note If you set [SCENE] to [WATER], you cannot set the white balance. [31] How to use Changing the Settings Shooting settings AE shift You can adjust the exposure according to your preference. 1.
You can change the image color tone when shooting movie/loop recording/Live streaming. 1. Press the NEXT button or PREV button to select [SETUP] - [COLOR], then press the ENTER button. 2. Press the NEXT button or PREV button to select the following setting, then press the ENTER button. NUTRL: Records in natural colors. VIVID: Records in vivid colors. BACK: Returns to the [COLOR] menu. Note If you shoot with [NUTRL], the image contrast may appear low. This is not a malfunction.
MP4: Records an MP4 movie. Select this setting if you want to upload to your smartphone or a website. BACK: Returns to the [V.FMT] menu. [34] How to use Changing the Settings Shooting settings Audio recording setting Set ON/OFF of the audio recording. 1. Press the NEXT button or PREV button to select [SETUP] - [AUDIO], then press the ENTER button. 2. Press the NEXT button or PREV button to select the following setting, then press the ENTER button. ON: Records sound when shooting a movie.
1. Press the NEXT button or PREV button to select [SETUP] - [WIND], then press the ENTER button. 2. Press the NEXT button or PREV button to select the following setting, then press the ENTER button. ON: Cuts low-range to reduce wind noise. OFF: Does not reduce wind noise. BACK: Returns to the [WIND] menu. Note This function does not activate while an external microphone is connected to this product.
The size of created movie is 15 minutes per file. 120mn: Sets the loop recording time to 120 minutes. The size of created movie is 15 minutes per file. UNLIM: Keeps recording continuously up to the limit of free space of a memory. The size of created movie is 15 minutes per file. The movie file is created up to the limit of free space of a memory. BACK: Returns to the [L.OPT] menu. Hint When [L.OPT] is set to [5min] The movie files of one minute per file are created in order.
120°: Records with a field angle of 120°. BACK: Returns to the [ANGLE] menu. [38] How to use Changing the Settings Shooting settings Still image mode switching You can set the mode for still image recording. 1. Press the NEXT button or PREV button to select [SETUP] - [DRIVE], then press the ENTER button. 2. Press the NEXT button or PREV button to select the following setting, then press the ENTER button. SINGL: Single shooting (Image size/5.4M) Shoots a single still image.
Try the following shooting methods. Stabilize the camera to prevent camera shake. Use the remote control function with a smartphone or Live-View Remote, or the self-timer function to prevent camera shake for better results. Make sure that the moving objects are not too large or too many. Shoot in a bright location and avoid changes in brightness. To shoot successfully in burst shooting mode Try the following shooting methods. Stabilize the camera to prevent camera shake.
Suitable for shooting slow-moving objects. BACK: Returns to the [FPS] menu. Note [10f1s], [5f2s], [2f5s] are estimates of the maximum speed. The maximum speed may not be reached depending on the shooting conditions. [40] How to use Changing the Settings Shooting settings Self-timer You can use self-timer when shooting still images. 1. Press the NEXT button or PREV button to select [SETUP] - [SELF], then press the ENTER button. 2.
[41] How to use Changing the Settings Shooting settings Interval photo recording You can select the time lapse setting for the interval photo recording mode. 1. Press the NEXT button or PREV button to select [SETUP] - [LAPSE], then press the ENTER button. 2. Press the NEXT button or PREV button to select the following setting, then press the ENTER button. 1sec: Continues to record still images at about 1-second intervals. 2sec: Continues to record still images at about 2-second intervals.
[42] How to use Changing the Settings Camera settings Wi-Fi connection You can operate the camera by using compatible devices (Live-View Remote, smartphone, etc.) connected to the camera via Wi-Fi. 1. Press the NEXT button or PREV button to select [SETUP] - [CONFG] - [Wi-Fi], then press the ENTER button. 2. Press the NEXT button or PREV button to select the following setting on the camera, then press the ENTER button. ON: Operates a single camera with the compatible device.
cases, the camera may be subject to unauthorized access, and any communication could be intercepted. [43] How to use Changing the Settings Camera settings GPS log You can record the location information and the movement speed while recording movies using the camera’s GPS function. Action Cam Movie CreatorTM allows you to import movies recorded with GPS log to your computer and view them with a map showing movement speed and tracking actions. 1.
You can also update the GPS assist data by inserting a memory card into the computer. Display the camera setting’s screen of Action Cam Movie Creator, select “Update GPS Assist Data” - the desired memory card drive to be installed on your computer, and then update the GPS assist data. If you insert this memory card into the camera, the GPS assist data will be reflected on the camera. Note GPS log is recorded only when recording movies. When you shoot still images, only the location information is recorded.
BACK: Returns to the [PLANE] menu. [45] How to use Changing the Settings Camera settings Mount Register the place of installation to the camera in advance. If you start shooting after registering the place of installation, the camera will detect every highlighted scene allowing you to make an appealing highlight movie with the Highlight Movie Maker. 1. Press the NEXT button or PREV button to select [SETUP] - [CONFG] - [MOUNT], then press the ENTER button. 2.
About user bit User bit is a function that can record information (8-digit hexadecimal numbers) such as date/time/scene number. This function is useful for editing movies created using two or more cameras. 1. Press the NEXT button or PREV button to select [SETUP] - [CONFG] - [TC/UB], then press the ENTER button. 2. Press the NEXT button or PREV button to select [DISP], [TCSET] or [UBSET], then press the ENTER button. When selecting [DISP] TC: Displays the time code. U-BIT: Displays the user bit.
Press the ENTER button to display [SURE?] while [OK] is displayed, then press the ENTER button again. FORMT: Selects the time code recording method. DF: Records the time code in drop frame. NDF: Records the time code in non-drop frame. In the following situations, the time code is fixed to [NDF]. When [VMODE] is set to 24p When [V.SYS] is set to [PAL] RUN: Sets how the time code advances. REC: The time code advances only while recording XAVC S movies.
RESET: Initializes the user bit. Press the ENTER button to display [SURE?] while [OK] is displayed, then press the ENTER button again. T.REC: Sets the recording time of the user bit. OFF: Does not record the time as a user bit. ON: Records the time as a user bit. BACK: Returns to the [UBSET] menu. Note When [V.FMT] is set to [MP4], [TC/UB] is not available.
Purchase it at a Sony service center. You can operate only the following settings using the RMT-845 (sold separately). Other settings are inoperable. Initialize the time code. When initializing the setting, the REC lamp lights in blue. Start/stop recording. [48] How to use Changing the Settings Camera settings HDMI settings Set the HDMI output signal. 1. Press the NEXT button or PREV button to select [SETUP] - [CONFG] - [HDMI], then press the ENTER button. 2.
OFF: Does not send the time code or user bit information. BACK: Returns to the [TCOUT] menu. * Unavailable when [V.FMT] is set to [MP4]. R.CTL: Controls the recording on a device connected with HDMI. ON: Controls the recording on the device. OFF: Does not control the recording on the device. BACK: Returns to the [R.CTL] menu. * Unavailable when [V.FMT] is set to [MP4]. BACK: Returns to the [HDMI] menu.
If you change the setting of the USB power supply while the micro USB cable is connected, disconnect the cable, then reconnect. Power may not be supplied properly from a USB device with a power supply capacity of less than 1.5 A. If you turn the power of the camera on while charging the battery pack, charging stops and power is supplied to the camera from a device connected via USB. You can shoot and playback images using USB Power supply, however the battery pack is not charged simultaneously.
When shooting movies, or shooting in Interval photo recording mode During movie playback When Wi-Fi connection is being established, Wi-Fi remote control is connected, an image is being uploaded to a smartphone, or live streaming HDMI connection is being made. Supplying power from a connected USB device Connecting a mass storage device IR-remote control is set to ON.
BACK: Returns to the [BEEP] menu. [52] How to use Changing the Settings Camera settings Date & time/area setting You can set the year/month/day and region. 1. Press the NEXT button or PREV button to select [SETUP] - [CONFG] - [DATE], then press the ENTER button. 2. Press the NEXT button or PREV button to select the desired date, time and region, then press the ENTER button to confirm. 2015 (default): Sets the year. 01 (default): Sets the month. 01 (default): Sets the day.
Setting the region You can set the clock to the local time of a country you visit by selecting the region. Regions are defined by time difference from Greenwich Mean Time (GMT). Refer also to “The list of time differences for world capitals”. Note Select 00:00 for midnight, 12:00 for noon. When you set the GPS log to [ON], the camera adjusts date, time and region automatically during shooting mode. [53] How to use Changing the Settings Camera settings Daylight Saving Time (Summer time) setting 1.
EN: Sets English. FR: Sets French. BP: Sets Brazilian Portuguese. TR: Sets Turkish. BACK: Returns to the [LANG] menu. [55] How to use Changing the Settings Camera settings Switching NTSC/PAL You can select the NTSC/PAL setting, depending on the TV system of the country or region where you use this camera. 1. Press the NEXT button or PREV button to select [SETUP] - [CONFG] - [V.SYS], then press the ENTER button. 2.
BACK: Returns to the [V.SYS] menu. 3. Press the NEXT button or PREV button, then press the ENTER button while [OK] is displayed on the display panel. To cancel the NTSC/PAL setting, press the NEXT button or PREV button while [OK] is displayed to select [CANCL], then press the ENTER button. Note When you change the NTSC/PAL setting, the camera will restart automatically. [56] How to use Changing the Settings Camera settings Version Displays the software version of the camera. 1.
Press a button. Eject the memory card. Connect/disconnect a cable. Insert/remove the battery pack. [58] How to use Changing the Settings Camera settings Resetting the settings You can reset the settings to their defaults. 1. Press the NEXT button or PREV button to select [SETUP] - [CONFG] - [RESET], then press the ENTER button. 2. Press the ENTER button to display [SURE?] while [OK] is displayed, then press the ENTER button again. The camera automatically restarts when resetting is complete.
[4K24p]: XAVC S movie (FDR-X1000V only) [4K24p] is only displayed when NTSC is selected. [HD]: XAVC S movie If you want to play back movie, select the item then press the ENTER button to start playing back. 7. Press the ENTER button. Stop playback. To control a content being played back Viewing the previous/next image: Press the PREV/NEXT button. Fast-rewind/fast-forward (movies only): Press and hold the PREV/NEXT button. Pause (movies only): Press the PREV and NEXT buttons simultaneously.
2. Select “Highlight Movie Maker” in “In-Camera Application Setting” from the “Settings” of the PlayMemories Mobile. 3. Press the icon to select a content format that you want to add in a highlight movie. 4. Select a movie that you want to add in a highlight movie from the date or the content list, then press the “Next” button. The highlight movie creation starts. You cannot select MP4 and XAVC S contents at the same time. You can select up to 100 movies by date or file.
Hint Use the “Settings” menu to change the movie length, BGM and the audio mix. 5. After creating the highlight movie, you can copy it to your smartphone. Hint Use the movie player application of a smartphone to play the copied highlight movie. Note Update PlayMemories Mobile to the latest firmware version in advance. The created highlight movie’s format is MP4. The following contents are not compatible with the highlight movie.
High speed recording The operation methods and display screens for the application are subject to change without notice by future. See more details about “PlayMemories Mobile” from the following website. (http://www.sony.net/pmm/) [62] How to use Create your movie Highlight Movie Maker Importing the BGM By default, this camera includes eight songs that you can use as background music while playing back a highlight movie.
Register the place of installation to the camera in advance. If you start shooting after registering the place of installation, the camera will detect every highlighted scene allowing you to make an appealing highlight movie with the Highlight Movie Maker. 1. Press the NEXT button or PREV button to select [SETUP] - [CONFG] - [MOUNT], then press the ENTER button. 2. Press the NEXT button or PREV button to select the following setting, then press the ENTER button.
5. Viewers 6. Comments from viewers The following settings must be configured for live streaming. Set the following distribution settings in the live streaming settings of the camera: User registration to USTREAM A smartphone (capable of tethering) or a Wi-Fi network environment *For more information about smartphone tethering settings or Wi-Fi network settings, refer to the operating instructions supplied with the smartphone or network service.
Streaming site, channel, image quality and the saving settings of the streaming site Title and description of streaming video SNS settings By configuring this setting, you can post a comment through social network services when starting streaming video. Connection settings for network services Comments you post About USTREAM USTREAM is a video sharing site through which you can stream and view videos with the Live Streaming function of this camera. For details of USTREAM, see the following site.
If you select Live Streaming mode, you can see the streaming status for Live Streaming with the REC lamp on the camera. FDR-X1000V HDR-AS200V 1: REC/LIVE lamp OFF: Before distribution Lights up in blue: Distributing Blinks slowly in blue (Approx. once per second): Distributing (There is an audience) Blinks fast in red (Approx. three times per second): Distribution error To stop the live distribution Press the REC button again.
You cannot live stream videos simultaneously using the same account on more than 1 camera. You need to connect using another account. Effects due to wireless communication conditions When connected using the tethering function of a smartphone or via a Wi-Fi router, images and sounds may be interrupted, or the communication may be cut off due to wireless communication conditions.
3. Display [Computer] - [PMHOME] - [INFO] - [WIFI_INF.TXT] on your computer, then check the user ID and password. Note Google play may not be supported depending on country or region. In this case, search for “PlayMemories Mobile” on the internet then install it. An NFC-enabled smartphone or tablet is required for using One-touch functions (NFC). The Wi-Fi function described here is not guaranteed to work with all smartphones and tablets.
[70] How to use your smartphone Using the camera connected to other devices via Wi-Fi Connecting to Using One-touch Functions to Connect to an NFCenabled Android Smartphone Perform preparation for connecting to your smartphone before connecting. 1. Select [SETUP] - [CONFG] - [Wi-Fi] - [ON] on the camera. 2. Confirm that the camera is in the shooting mode. LOOP: Loop recording mode MOVIE: Movie mode PHOTO: Photo mode INTVL: Interval photo recording mode 3.
Perform preparation for connecting to your smartphone before connecting. 1. Select [SETUP] - [CONFG] - [Wi-Fi] - [ON] on the camera. 2. Confirm that the camera is in the shooting mode. LOOP: Loop recording mode MOVIE: Movie mode PHOTO: Photo mode INTVL: Interval photo recording mode 3. Connect your smartphone. Android 1. Start PlayMemories Mobile on the smartphone. 2. Select the SSID that is printed on the sticker attached to Startup Guide. 3. Input the password on the same sticker (First time only).
iPhone/iPad 1. Open [Settings] and select [Wi-Fi] on the smartphone. Select the SSID that is printed on the sticker attached to Startup Guide. 2. Input the password on the same sticker (First time only). 3. Confirm that the SSID of the camera is displayed on the smartphone.
4. Return to the Home screen, then start PlayMemories Mobile. Note When the airplane mode is set to [ON], the Wi-Fi function is not available. You cannot connect a smartphone to multiple cameras at the same time. Depending on local electrical interference or the smartphone’s capabilities, the live view images may not be displayed smoothly.
Press the NEXT button or PREV button to select [SETUP] - [CONFG] - [Wi-Fi] - [ON], then press the ENTER button. 3. Select the SSID that is printed on the sticker attached to Startup Guide. 4. When this camera beeps and [ACPT?] is displayed on the display panel of this camera, press the ENTER button of this camera. Note When [BEEP] is set to [OFF], the connection beep does not sound.
connection) You can operate this camera using a Handycam that supports the multi camera control function. 1. Turn on the Handycam. For details, refer to “Connecting this product to one camera with Multi Camera Control (Single Connection)” in the Help Guide of the Handycam. Example: Help Guide of FDR-AX30/AXP35 http://rd1.sony.net/help/cam/1510/h_zz/ 2. Set the connection mode of the camera. Press the NEXT button or PREV button to select [SETUP] - [CONFG] - [Wi-Fi] - [ON], then press the ENTER button. 3.
[CRRNT], then press the ENTER button. 3. If you will continue to connect multiple cameras, repeat from step 2. Note When [BEEP] is set to [OFF], the connection beep does not sound. [76] How to use Movie Creator Editing images imported to your computer Using the Action Cam Useful functions of Action Cam Movie Creator Action Cam Movie CreatorTM allows you to import movies to your computer to use them in various ways. Visit the following URL to install the software. http://www.sony.
Installing Action Cam Movie Creator on your computer Install Action Cam Movie Creator™ on your computer. Follow the steps below. 1. Turn on the computer. Log on as an Administrator. Close all applications running on the computer before installing the software. 2. Visit the following URL with the Internet browser of the computer and install Action Cam Movie Creator. http://www.sony.net/acmc/ When installation is complete, Action Cam Movie Creator starts up. 3.
Do not disconnect the micro USB cable (supplied) from the camera while the computer screen indicates that the camera is being operated or accessed. Doing so may cause data corruption. To disconnect the computer from the camera, click on the task tray then click (Icon to remove). If you are using Windows Vista, click on the task tray.
[79] How to use Others Recordable time Estimated recording time of movies XAVC S 4K Average recording time (FDR-X1000V) Recorded image: 100 Mbps When using 64GB memory card: Approx. 75 minutes Recorded image: 60 Mbps When using 64GB memory card: Approx. 125 minutes XAVC S HD Average recording time (FDR-X1000V) Recorded image: 100 Mbps When using 64GB memory card: Approx. 75 minutes Recorded image: 60 Mbps When using 64GB memory card: Approx.
The recordable time may vary depending on the recording conditions, subjects, and the image quality setting. Continuous movie shooting time is approximately 13 hours. [80] How to use Others Recordable time Estimated number of recordable still images Number of pixels: 2M (Interval photo recording) (16:9) When When When When using using using using 8GB memory card: 6800 images 16GB memory card: 13500 images 32GB memory card: 27500 images 64GB memory card: 40000 images Number of pixels: 8.
The battery pack will run out quickly if you use the playback, fast-forward, and fast-rewind frequently. Turn off the camera every time you do not shoot or playback on the camera. Battery pack is wearing out when the shooting is in standby. We recommend having spare battery packs handy for two times or three times the expected shooting time, and making trial shots before taking the actual shots.
[86] How to use Others Using the camera abroad On TV color systems To view images shot by the camera on a TV, you need a TV (or monitor) with an HDMI jack and a micro HDMI cable (sold separately). Before shooting, be sure to set [V.SYS] to the TV system of the country and region where you will view recordings. [87] How to use Others Using the camera abroad Countries and regions where you can view images when [V.
Moscow/Nairobi +03:00 Tehran +03:30 Abu Dhabi/Baku +04:00 Kabul +04:30 Karachi/Islamabad +05:00 Kolkata/New Delhi +05:30 Almaty/Dhaka +06:00 Yangon +06:30 Bangkok/Jakarta +07:00 Hong Kong/Singapore/Beijing +08:00 Tokyo/Seoul +09:00 Adelaide/Darwin +09:30 Melbourne/Sydney +10:00 New Caledonia +11:00 Fiji/Wellington +12:00 Midway -11:00
Hawaii -10:00 Alaska -09:00 San Francisco/Tijuana -08:00 Denver/Arizona -07:00 Chicago/Mexico City -06:00 New York/Bogota -05:00 Santiago -04:00 St.John’s -03:30 Brasilia/Montevideo -03:00 Fernando de Noronha -02:00 Azores, Cape Verde Is. -01:00 [90] How to use Others Precautions Do not use/store the camera in the following places In an extremely hot, cold or humid place In places such as in a car parked under the sun, the camera body may become deformed and this may cause a malfunction.
in some cases may be irreparable. [91] How to use Others Precautions On carrying Do not sit down in a chair or other place with the camera in the back pocket of your trousers or skirt, as this may cause malfunction or damage the camera. [92] How to use Others Precautions Care and storage of the lens Wipe the surface of the lens clean with a soft cloth in the following instances: When there are fingerprints on the lens surface.
[95] How to use Others Precautions On moisture condensation If the camera is brought directly from a cold to a warm location, moisture may condense inside or outside the camera. This moisture condensation may cause a malfunction of the camera. If moisture condensation occurs Turn off the camera and wait about 1 hour for the moisture to evaporate.
the camera. GPS is a system that determines your position by receiving signals from satellites. Avoid using the GPS feature on your camera in places where radio signals are blocked or reflected, such as a shadowy place surrounded by buildings or trees, etc. Use the camera in open sky environments. You may not be able to record location information at locations or in situations where radio signals from the GPS satellites do not reach the camera as follows.
Specifications FDR-X1000V [System] Video signal: UHDTV HDTV NTSC color, EIA standards PAL color, CCIR standards Image device: 1/2.3 type (7.81 mm) Exmor R CMOS sensor Pixel Gross: Approx. 12.8 megapixels Effective picture resolution (movie): Approx. 8.8 megapixels (16:9) (SteadyShot is set to [OFF]) Effective picture resolution (still): Approx. 8.79 megapixels (16:9) Still image max effective: Approx. 8.79 megapixels (16:9) Interval photo recording mode: Approx. 2.
[Power] Power requirements: Rechargeable battery pack: 3.6 V (NP-BX1 (supplied)) Multi/Micro USB Terminal: 5.0 V Charging method: USB charging: DC 5.0 V, 500 mA/800 mA Charging time: Via a computer NP-BX1 (supplied): Approx. 4 h 5 min. Via the AC-UD10 (sold separately) NP-BX1 (supplied): Approx. 2 h 55 min. Power supply method: USB power supply (1.5 A or more is recommended) Power consumption: 2.
Dimensions: Approx. 39.0 mm × 74.3 mm × 95.9 mm (1 9/16 in. × 3 in. × 3 7/8 in.) (W/H/D, including protrusions) Mass: Approx. 84 g (3 oz) Pressure-resistance: Shooting underwater at a depth of 10 m (33 feet) for 60 continuous minutes is possible. * * When the camera is inserted. Attachment Buckle: Dimensions: Approx. 47.0 mm × 14.0 mm × 58.5 mm (1 7/8 in. × 9/16 in. × 2 3/8 in.) (W/H/D, including protrusions) Mass: Approx. 16 g (0.57 oz) Flat Adhesive Mount: Dimensions: Approx. 53.0 mm × 13.0 mm × 58.
movies) Still images: JPEG (DCF Ver. 2.0, Exif Ver. 2.3, MPF Baseline) compliant Recording media: When recording MP4 movies: Memory Stick Micro (Mark2) media microSD/SDHC/SDXC card (Class4 or faster) When recording XAVC S (50Mbps) movies: microSDXC card (Class10 or faster) [Input and Output connectors] Multi/Micro USB Terminal *: micro-B/USB2.0 Hi-Speed (Supports Micro USB compatible devices.) *USB connenction is only for output.
Speaker: Monaural * Splashproof performance is based on standard testing by Sony. [Wireless LAN] Corresponding standard: IEEE 802.11b/g/n Frequency: 2.4 GHz Supported security protocols: WPA-PSK/WPA2-PSK Configuration method: WPS (Wi-Fi Protected Setup) Access method: Infrastructure Mode NFC: NFC Forum Type 3 Tag compliant [Accessories] Tripod Adaptor: Dimensions: Approx. 23.0 mm × 14.0 mm × 48.7 mm (29/32 in. × 9/16 in. × 1 15/16 in.) (W/H/D, excluding protrusions) Mass: Approx. 12 g (0.
Corporation in the United States and/or other countries. Mac is a registered trademark of Apple Inc. in the United States and other countries. Intel, Pentium and Intel Core are trademarks of Intel Corporation in the U.S. and/or other countries. Adobe, the Adobe logo, and Adobe Acrobat are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. microSDXC logo is a trademark of SD-3C, LLC.
The default setting of every setting item is as follows. Image quality setting 1080 30p HQ (When you set [V.FMT] to [MP4]) 1080 60p/50p 50M (When you set [V.FMT] to [HD]) 2160 30p/25p 60M (When you set [V.
Wi-Fi connection ON GPS log ON Airplane mode OFF Mount BODY Time Code/User Bit OFF (When you set [DISP]) DF (When you set [FORMT] of [TCSET]) REC (When you set [RUN] of [TCSET]) PrSet (When you set [MAKE] of [TCSET]) OFF (When you set [T.REC] of [UBSET]) IR-Remote Control OFF HDMI settings AUTO(When you set [RESOL]) 60p (When you set [24/60]) OFF (When you set [TCOUT]) OFF(When you set [R.
Troubleshooting If you experience trouble with the camera, try the following solutions. 1. Check the items of troubleshooting and inspect the camera. 2. Turn the power off this unit and then on again one minute later. 3. Consult your Sony dealer or local authorized Sony service facility by phone. [106] Troubleshooting Troubleshooting Battery pack and power Cannot turn on the camera. Attach a charged battery pack. Make sure that the battery pack is inserted correctly.
[109] Troubleshooting Troubleshooting Battery pack and power Cannot charge the camera. Turn off the camera and make the USB connection. Disconnect the micro USB cable (supplied), and then reconnect it. Use the micro USB cable (supplied). Charge the battery pack in an ambient temperature of 10°C to 30°C (50°F to 86°F). Turn on the computer and connect the camera. Release the computer from sleep or hibernation status. Connect the camera directly to a computer using the micro USB cable (supplied).
The camera does not have a feature for superimposing dates on images. [114] Troubleshooting Troubleshooting Viewing images Cannot playback images. The folder/file name has been changed on your computer. Connect a micro HDMI cable (sold separately). [115] Troubleshooting Troubleshooting Viewing images The image does not appear on the TV. Check whether the connection is correct. [116] Troubleshooting Troubleshooting GPS The camera is not receiving a GPS signal. Set the GPS log to [ON].
is taken in. Date & Time Setting is not set, or set time is shifted greatly. Set the date and time correctly. The term of validity of GPS assist data has expired. Update GPS assist data. As the positions of GPS satellites vary constantly, it may take longer to determine the location or the receiver may not be able to determine the location at all, depending on the location and time you use the camera. GPS is a system for determining geographic location by triangulating radio signals from GPS satellites.
Action Cam Movie Creator cannot be installed. Check the computer environment or installation procedure required to install Action Cam Movie Creator. [123] Troubleshooting Troubleshooting Computers Action Cam Movie Creator does not work correctly. Quit Action Cam Movie Creator and restart your computer. [124] Troubleshooting Troubleshooting Computers Cannot play back images on your computer. Consult the computer or software manufacturer.
time. This is not a malfunction. [128] Troubleshooting Troubleshooting Others The date or time is incorrect. Set the date and time again. [129] Troubleshooting messages Warning indicators and messages Warning indicators and error Warning indicators and error messages Battery indicator (Remaining battery is low) When the battery level is low, is displayed. Charge the battery pack immediately. ERROR Turn the power off and then on again.
SHORT The remaining capacity of the memory card is insufficient for loop recording. FULL Remaining capacity of the memory card is insufficient for recording. MAX The maximum number of files that can be recorded has been reached. MEDIA The memory card is not inserted properly. The memory card is damaged. The memory card does not support XAVC S movie recording. NoCRD There is no memory card inserted. NoDSP The camera is not connected to a TV when playback is started.
network. Some other network error has occurred. Confirm the setting of the access point or the security of the access point using “Camera Settings for Live Streaming” of the Action Cam Movie Creator’s camera settings. NO AP Access point cannot be found. Confirm the setting of the access point using “Camera Settings for Live Streaming” of the Action Cam Movie Creator’s camera settings. LIMIT The total time of saved video on USTREAM has reached the limit. Stop streaming video.
