FUSION R400P ™ 4-Drive Serial ATA Rackmount Storage System with Port Multiplier User’s Guide For Windows
Fusion R400P Specifications and Features Drive Presence LED (Bay 1) Power LED Drive Presence LED (Bay 2) Drive Presence LED (Bay 3) Drive Presence LED (Bay 4) Drive Module Drive Module Drive Module Drive Module (Bay 1) (Bay 2) (Bay 3) (Bay 4) Drive Activity LED (Bay 3) Drive Activity LED (Bay 4) Power switch Drive Activity LED (Bay 1) Drive Activity LED (Bay 2) Figure 1 Host Communication LED 4 3 2 1 Drive Activity LEDs (numbers indicate bays) eSATA Port Power Cable Connector Figure 2
Safety Precautions and Disclaimers SAFETY PRECAUTIONS DISCLAIMERS (continued) Please read this section carefully before proceeding. These precautions explain the correct and safe use of this device, thereby helping to prevent injury to you or others, and also help you to minimize the risk of damaging the device. Drive Usage: Sonnet Technologies has qualified the hard drives listed below for use in Fusion R400P storage systems.
Drive Installation and Enclosure Setup 1. Remove the Fusion R400P from its packaging, and place it on a flat, level surface. foot 2. If you intend to use the Fusion enclosure on a desktop or other flat surface, attach the included adhesive-backed feet to the bottom of the enclosure (Figure 3). 3. If you intend to use the Fusion enclosure in a rack, install the Sonnet rack slide set (or equivalent), sold separately: • FUS-RSS-P for 17–21.5" deep racks • FUS-RSS-S for 23–26.5" deep racks • FUS-RSS for 27–30.
Tips and Additional Information Contacting Sonnet Customer Service This section covers some common sense tips for using the Fusion R400P enclosure. USA Customers The Sonnet Web site located at www.sonnettech.com has the most current support information and technical updates. Before you call Sonnet Customer Service, please check our Web site for the latest updates and online support files, and check this User’s Guide for helpful information.
