User's Guide

Appendix A for US
100 19.00-20.50
15 MHz
1
QPSK
20.80-23.00
36 20.00-21.50
75 20.00-21.00
1
16QAM
20.00-22.00
36 19.00-20.50
75 19.00-20.50
10 MHz
1
QPSK
22.00-23.50
25 21.00-22.50
50 21.00-22.50
1
16QAM
21.00-23.00
25 20.00-21.50
50 20.00-21.50
5 MHz
1
QPSK
22.00-23.00
12 21.00-22.50
25 21.00-22.50
1
16QAM
21.00-22.50
12 20.00-21.50
25 20.00-21.00
3 MHz
1
QPSK
22.00-23.30
8 21.00-22.00
15 21.00-22.00
1
16QAM
21.00-22.50
8 20.00-21.50
15 20.00-21.50
1.4 MHz
1
QPSK
22.00-23.00
3 22.00-23.30
6 21.00-22.00
1
16QAM
21.00-22.50
3 21.00-22.50
6 20.00-21.50
Normal Mode RF Power Range (WLAN/Bluetooth)
Band (GHz) Mode Range(dBm)
WIFI 2.4G 802.11b 11.00-12.80
