User's Guide

Appendix A for US
25 20.50-21.60
Mode
Bandwidth
RB Modulation Range(dBm)
LTE Band 41
20 MHz
1
QPSK
23.20-25.00
50 23.50-25.00
100 23.50-25.00
1
16QAM
23.20-25.00
50 23.50-25.00
100 23.50-25.00
15 MHz
1
QPSK
23.00-24.80
36 23.50-24.80
75 23.50-24.80
1
16QAM
23.50-24.80
36 23.50-24.80
75 23.50-24.80
10 MHz
1
QPSK
23.00-24.50
25 23.00-24.50
50 23.00-24.50
1
16QAM
23.50-24.60
25 23.00-24.60
50 23.00-24.60
5 MHz
1
QPSK
21.00-24.50
12 23.00-24.50
25 23.00-24.50
1
16QAM
23.50-24.50
12 23.00-24.50
25 23.00-24.50
Mode
Bandwidth
RB Modulation Range(dBm)
LTE Band 66 20 MHz
1
QPSK
21.00-23.50
50 20.00-21.50
100 20.00-21.50
1
16QAM
20.00-23.00
50 19.00-20.50
