User's Guide

Appendix A for US
3 22.50-23.50
6 21.50-22.50
Mode
Bandwidth
RB Modulation Range(dBm)
LTE Band 7
20 MHz
1
QPSK
21.00-23.00
50 21.00-22.50
100 21.00-22.50
1
16QAM
21.00-23.00
50 20.00-21.50
100 20.00-21.50
15 MHz
1
QPSK
21.50-23.00
36 21.00-22.50
75 21.00-22.50
1
16QAM
20.00-22.50
36 20.00-21.50
75 20.00-21.50
10 MHz
1
QPSK
21.00-23.50
25 21.00-22.50
50 21.00-22.50
1
16QAM
20.00-22.50
25 20.00-21.50
50 20.00-21.50
5 MHz
1
QPSK
21.00-23.00
12 21.00-22.50
25 21.00-22.50
1
16QAM
20.00-22.50
12 20.00-21.50
25 20.00-21.50
Mode
Bandwidth
RB Modulation Range(dBm)
LTE Band 12 10 MHz
1
QPSK
23.50-25.00
25 22.50-23.50
50 22.50-23.50
