SonicWALL NSA E6500 Getting Started Guide Page 7
The Back Panel
Icon Feature Description
Expansion Bay Future extension.
Fans (2) The SonicWALL NSA E6500 includes two fans for system temperature control.
Power Supply The SonicWALL NSA E6500 power supply.
