Page 4 Check Package Contents
Check Package Contents
Before setting up your SonicWALL NSA E6500, verify that your
package contains the following parts:
SonicWALL NSA E6500
DB9 -> RJ45 (CLI) Cable
Standard Power Cord *
Rack Kit
Ethernet Cable
Red Crossover Cable
1
2
3
4
5
6
Release Notes
Global Support Services Guide
Thank You Card
Getting Started Guide
7
8
9
9910
Any Items Missing?
If any items are missing from your package, please contact
SonicWALL support.
A listing of the most current support options is available online at:
<http://www.sonicwall.com/us/support.html>
*The included power cord is intended for use in North America only. For
European Union (EU) customers, a power cord is not included.
1
E6500
Network Security Appliance
SonicOS Release Notes
Contents
5 6
2
4
3
9
7 8
10
