SonicWALL NSA E6500 Getting Started Guide Page 3
Pre-Configuration Tasks
In this Section:
This section provides pre-configuration information. Review this section before setting up your SonicWALL NSA E6500.
• Check Package Contents - page 4
•
Obtain Configuration Information - page 5
•
The Front Panel - page 6
•
The Back Panel - page 7
•
Front Bezel Control Features - page 8
•
Front Bezel Configuration Example - page 12
