Page 2 SonicWALL NSA E6500
SonicWALL NSA E6500
Note: Always observe proper safety and regulatory guidelines when removing administrator-serviceable parts from the SonicWALL
NSA E6500. Proper guidelines can be found in the Product Safety and Regulatory Information section, on page 69 of this
guide.
I
o
PML
Front
Back
1U rack-mountable
17 x 16.75 x 1.75 in
43.18 x 42.54 x 4.44 cm
17.30 lbs/7.9 kg
17.30 lbs/7.9 kg
E6500
Network Security Appliance
Form Factor
Dimensions
Weight
WEEE Weight
NSA_E6500_GSG.book Page 2 Wednesday, June 17, 2009 7:16 PM
