Chapter 6. OPERATION
6-9
■ Program selection
The program can be selected in the program operation READY mode. The table below
shows program selection by external switch inputs. Two external switch states are pro-
vided for selection of programs 10 to 15. When program selection by external switch
inputs is set to “0”, the program can be selected by the console keys and by communica-
tion with a personal computer.
External Weighting State
Switch No.
RSW8 1 OFF ON OFF ON OFF ON OFF ON OFF ON
RSW9 2 OFF OFF ON ON OFF OFF ON ON OFF OFF
RSW10 4 OFF OFF OFF OFF ON ON ON ON OFF OFF
RSW11 8 OFF OFF OFF OFF OFF OFF OFF OFF ON ON
RSW12 10 OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF
Program No. Selection 0123456789
External Weighting State
Switch No.
RSW8 1 OFF OFF ON ON OFF OFF ON ON OFF OFF ON ON
RSW9 2 OFF ON OFF ON ON OFF ON OFF OFF ON OFF ON
RSW10 4 OFF OFF OFF OFF OFF ON OFF ON ON ON ON ON
RSW11 8 OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON
RSW12 10 ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF
Program No. Selection 10 11 12 13 14 15
External Weighting State
Switch No.
RSW8 1 OFF ON OFF ON OFF ON OFF ON OFF ON
RSW9 2 ON ON OFF OFF ON ON OFF OFF ON ON
RSW10 4 ON ON OFF OFF OFF OFF ON ON ON ON
RSW11 8 OFF OFF ON ON ON ON ON ON ON ON
RSW12 10 ON ON ON ON ON ON ON ON ON ON
Program No. Selection 16 17 18 19 0
