Chapter 5. FUNCTIONS
5-19
● 0D, 6D output
AT execution
Over-range
MANUAL mode
PID control operation
Initialization of PID control operation
Output change limitter
Output upper/lower limit limitter
Voltage output 1 adjustment
Time-proportional relay output
Time-proportional voltage output
Output 1
Manipulated variable (MV1)
Output 1 time-proportional output cycle
ON/OFF control
MV at over-range
READY mode
MV in READY mode
Preset manual value
Manual MV
AT operation
ON/OFF control operation
Setting: PID parameters p/ 1 / d/RE
PID parameters dP/di /dd
PID parameters br
Setting: Variable parameters OTL
Setting: PID parameters OL/OH
Setting: Variable parameter AT
Setting: Setup data C 12/C 13
Setting: Setup data C 14/C 15
Setting: Variable parameter DI FF
Setting: Setup data C 16
(6D output)
Setting: Setup data C78
Setting: Variable parameter Cy. 1
Setting: Variable parameters 1 OUT/rpi d
In ON-OFF control, the DCP301
cannot be set to the MANUAL
mode. (The DCP301 can be set to
the MANUAL mode as ON-OFF
control is not possible in the
READY mode.)
