Table Of Contents
- CP-UM-5093E-04.pdf
- SAFETY PRECAUTIONS
- Contents
- Chapter 1. GENERAL
- Chapter 2. NAMES & FUNCTIONS OF PARTS
- Chapter 3. MOUNTING
- Chapter 4. WIRING
- 4-1 Wiring Precautions
- 4-2 Compensating Lead
- 4-3 Terminal Connections
- 4-4 Layout of Terminals and Recommended Lead Draw-out Direction
- 4-5 Connecting the Ground and Power Supply
- 4-6 Wiring of Standard and Add-on Terminal Base
- 4-7 Connecting Inputs (analog inputs)
- 4-8 Connecting control outputs (outputs 1, 2)
- 4-9 Connecting auxiliary outputs (outputs 2, 3)
- 4-10 Connecting Event Output (relay output)
- 4-11 Connecting Time Event Output (open-collector)
- 4-12 Connecting External Switch (RSW) Input
- 4-13 Connecting for Communications
- 4-14 Isolating Inputs and Outputs
- Chapter 5. FUNCTIONS
- Chapter 6. OPERATION
- Chapter 7. PARAMETER SETUP
- Chapter 8. PROGRAM SETUP
- Chapter 9. TROUBLESHOOTING
- Chapter 10. SPECIFICATIONS
- Chapter 11. CALIBRATION
- Index
Chapter 1. GENERAL
1-1
Chapter 1. GENERAL
1-1 Features
The DCP301 is a general-purpose single-loop program controller for controlling temperature, pressure, flow rate and
other inputs.
● High accuracy achieved by multi-range input
Multi-range input allows you to choose between the following input types: thermocouple,
resistance temperature detector (RTD), dc voltage and dc current. Accuracy of ±0.1%FS±1
digit and a sampling cycle of 0.1s ensures consistently high-precision control.
● Wide range of control output types
A wide range of models supporting various control output types are available: relay time-
proportional output, position-proportional output, current output, voltage time-propor-
tional output, and heat/cool output.
On models other than heat-cool control output, you can also choose neural net-based
auto-tuning and smart-tuning for inhibiting overshoot, in addition 2 degrees of freedom
PID.
● Enhanced compatibility with PLC
12 external switch inputs (eight optional), three event outputs and five time event outputs
(optional) ensure compatibility with automating systems designed around a PLC core.
● Easy operation
Up to eight frequently changed parameter setups can be registered to the
PARA
key, facili-
tating recall of item setups.
If the Smart Loader Package (sold separately) is used together with the DCP301, pro-
grams and parameters can be set up on a personal computer.
