External Radio Unit Installation Guide
Tools and materials
Make sure you have the following items on hand before you begin.
To install the ERU on brick or poured concrete
1
Hold the mounting bracket-and-pipe assembly in position on the mounting
surface.
2
Use a level to verify that the center line of the mounting bracket is perfectly
vertical.
3
Use a pencil or a piece of chalk to mark the position of the four holes that are
located in the four corners of the mounting bracket.
4
Remove the mounting bracket-and-pipe assembly.
5
Drill a 1/2-inch hole in each of the locations you marked.
6
Insert a double-expansion anchor in each hole.
Materials Tools
Four B4015 or equivalent double-expansion
anchors
Electric drill with a 1/2-inch masonry bit
Four 1/4-inch -20 x 3-inch machine screws Carpenter’s level
Screwdriver
Hammer
11-mm (7/16-inch) open-end or box-end
wrench or a small adjustable wrench
Pencil or chalk
