Section4
4.1 Installation
This chapter describes how to install each unit and optical cables. It also explains how to install
shelves or enclosuers of each unit, power cabling method and optical cabling and RF interface.
Required accessories and tools for installation are list up in the below table.
4.2 Required Materials
Installation
Step
Accessory Included Tool Remark
Remote
Enclosure
Installation
M12 Bolt (4EA) X
Spanner
(19mm)
-
Power
Connection_AC
AC 120V power cable (1EA)
[2 meter, with MIL-5015 type Connector (MS-3106A- 18-10S)
at one end, AC Plug at another end]
○
- -
Ground
Connection
M6 Screw (1EA)
○
#2
Screwdriver
(+)
For
more
details,
refer to
4.3.3.
Lug (1EA)
○
Crimping
tool
Max. AWG #6 Cable X
Optical
Connection
Optical Cable Assembly Connector (1EA)
[957-5004-105, by Amphenol]
○
-
For
more
details,
refer to
4.3.4.
OPTIC SC/APC Cable (1EA) X -
Antenna
Connection
4.3-10 DIN(M) RF Cable (1 or 2EA) X -
2 EA are
required
in case
