4.1 REMOTEUNITInstallation
4.1.1 RE MOTEUNITEnclosureinstallation
REMOTEUNITisdesignedtobewater‐anddirt‐proof.TheunithasthestructureofOne‐Bodyenclosure.
Itsatisfieswater‐proofandquake‐proofstandardsequivalentofNEMA4.
REMOTE UNIT can be mounted on either ceil or the Wall. Basically, REMOTE UNIT has both of a Wall
MountBracket.
Thefollowingshowsdimensionofthefixingpointfor theWallMountBracket.

Figure4.1–ExteriorofRemoteUnit
