5.2 RFper formance
Supported Services
Supported Services
700LTE
Full Band
800
Sprint/850
Cellular
1900
PCS
2100
AWS
Frequency
Range
Tx (MHz) 728-756 862-894 1930-1995 2110-2155
Rx (MHz)
698-716
777-787
817-849 1850-1915 1710-1755
Bandwidth
Tx (MHz) 28 32 65 45
Rx (MHz)
18
10
32 65 45
RF Parameters
Input Power
Tx (dBm) -20 to +10 -20 to +10 -20 to +10 -20 to +10
Rx (dBm) ≤ -50 ≤ -50 ≤ -50 ≤ -50
Output Power
Tx (dBm) 37 37 37 37
Rx (dBm) 0 0 0 0
System Gain
Tx (dBm) 57 57 57 57
Rx (dBm) 50 50 50 50
System Delay
Tx < 8µs < 8µs < 8µs < 8µs
Rx < 8µs < 8µs < 8µs < 8µs
Impedance
Tx (ohm) 50
Rx (ohm) 50
Spurious
Emissions
Tx ≤ -13dBm @ 9kHz – 5GHz
Out of Band
Attenuation
Rx ≤ 45dB @ F_edge ± 1MHz offset
Gain Control
Range/Step
Tx 25dB/step 1dB
Rx 20dB/step 1dB
Optical
Optic
Wavelength
Tx 1310nm WDM
Rx 1550nm WDM
Optic Link AGC Above 10dB
Optic Link Loss Max 10dBo
Noise Figure 8dB Max
Optical Connector SC-APC (Single Mode Fiber)
RF Connector DIN-F (Common Output), N-F (UHF/VHF and AOR)
Monitoring Port -30dB (SMA Female)
