4.1.4 GNDTerminalConnection
TheGroundTerminalislocatedatthelefsideofRemoteUnit.

Groundingmustbecarriedout.Connectanearth‐bondingcabletothegroundingconnctionprovidedat
theoutsideoftheRemoteUnit(atleftside).
Afterlosseningthehexbolt,connecttheearth‐bondingcablebetweentheenclosureand
hexbolt.Then,
fastenallpartsagainwiththehexbolt.

 Roundterminalslocatedonthesideofa0.75mm
2
(18AWG)ormorewiresUsingpermanently
connectedtoearth(green/yellowcolor)


