Thischapter describeshowtoinstalleachunitandopticalcables,alongwithpowercablingmethod.In
detail, thechapter describes how to install shelves or enclosuers of each unit, Power Cabling method
andOpticCablingandRFInterface.
Theneededaccessoriesandtoolsarelistupinthebelowtable.


Stepsforinstallation Accessories Included Tool Remark
RemoteEnclosureInstallation M12Bolt(6EA) X Spanner(19mm)
Power&
OpticConnection
Cable for compression
connector(HBG‐114‐1)
X Installation manual
providedbyRFS

Optic:SC‐APC X
Power :
20020517M031B01LF(FCI)
O “4mm” Screw
driver(for slotted
screw)

AntennaConnection DIN 7/16 CONNECTOR
(Male), Coaxial cable for
DIN7/16
X‐ 


