‐11dBm 9dB 0dBm 20dB +10dBm 30dB
‐10dBm 10dB 

TheMDBUcards intheBIUprovideALC(AutoLevelControl)functionalityforeach oftheinputsto
limit the maximum power output per carrier input. The input level starts activating ALC at‐20dBm
when turning the ALC on.For correct parameter settings, first, perform the input AGC and then
turntheALCfunctionon.

Edit the port name and set it as a desired character string (up to 12 characters).For example, the
figurebelowshowsascreenwhenyouset“VzW”forport1and“AT&T”forport2.

Figure6.4–MDBUnameassignmentattheBIU

Thisnamingisreflectedatthetreeasfollows

Figure6.5–MDBUnameassignmentatthetree

Usevariousupper/lowerlimits.Thefollowingtableshowsrecommendedlimitsettings:
Item RecommendedLimit Remark
TXINHIGHALM 15dBm Alarm
TXINLOWALM‐25dBm Alarm
RXOUTALC 0dBm AutoLevelcontrol
RXOUTHIGHALM 5dBm Alarm
After you finish setting normal input levels and alarm limits, check to see if the MODULE FAILURE
LEDIndicatorislitgreen(Normalcase).
