Figure5.27–OpticalcablewithSC/ACPTypeConnectors
SC/APC type connectors must be used. To prevent  the optical access part from being marred with
dirt,itshouldbecoveredwithacapwhennotinstalled.Connectorsshould becleanedwithalcohol
beforetheyareinstalled.

5.4.4 DOUinstallationwithanOEU
UptotwoDOUscanbeinsertedintoanOEUchassis.TheDOUmoduleisaPluginPlaytype.
When you insert the DOU into the OEU, insert it into the top DOU 1 slot first. Slot numbers are
silkscreenedontheleft.
Thefollowingfigureshowsinstallationdiagramof
anOEUwithoneDOUinsertedinit.

ThefollowingfigureshowsinstallationdiagramofanOEUwithtwoDOUsinsertedinit.

Figure5.28–OEUwithDOUsinserted


 WhenyouinsertaDOUintoOEU,usetheDOU1slotfirst.Forunusedslots,youneddtoinstall
