User's Manual

Confidential&Proprietary80/115 SC‐DAS

ROUcomponents
TheROUhasthefollowingcomponents:
No. Unit Description Remark
MRU
Enclosure IncludingWallcradle 1EA
PowerCable
‐Connectorwith3holetoAC120plug(AC)
‐Connectorwith2lugtermination(DC)
1EA(Optical for
ACorDC)
ARU
Enclosure IncludingWallcradle 1EA
PowerCable
‐Connectorwith3holetoAC120plug(AC)
‐Connectorwith2lugtermination(DC)
1EA(Optical for
ACorDC)
RF cable for
optical
‐TwoRFcablesandonesignalcable 
RF cable for
antenna
‐TwoRFcables

5.3.2 ROUPowerCabling
TheROUsupportsbothofDC‐48VandAC120Vinputpower.ThetypeofinputpowerfortheROUis
alreadydeterminedatthefactory.TheROUisshippedwiththecorrectpowercableinthepackage
box. See the UL name plate of the ROU todetermine theinput power
 type of the ROU or see the
powerconnectorinthebelowpicture.Youshouldorderthetypeofinputpowerasyourapplication.

(a)AC/DC(b)DC/DC
Figure5.22–ROUPowerPortview
Checkifyour powercordconnector isthesameas one seenin the tableabove. TheROUdoes not
havepowerswitchtopoweron/off.PowersupplyisonwhencordispluggedintotheACsource.

