ROURackMountInstallation
Therearetwowaystoinstallrackmount.OneistoinstallROUsontherackvertically:theotheristo 
installROUsontherackhorizontally

Type1:Verticalinstallationontherack
Forvertcalinstallation,averticalbracketisneeded.
First,installbracketforverticalinstallationontherack

Second,mountMRUontheleftsideoftheinstalledbracket
Third,mountARUontherightsideoftheinstalledbracket
Completedinstallationdiagramisasfollows


Figure5.18–ROUinstallationprocedureforverticalrack

Thefollowingshowsdimensionofthemountingpointforverticalinstallation
