User's Manual

Confidential&Proprietary69/115 SC‐DAS


Figure5.10–CablinginterfacediagrambetweenBIUandODU


 ForunusedRFPortsforODUexpansion,makesuretoterminatethemusingSMATerm.


 WheninstallinganODUabovetheBIU,itisrecommendedtoleaveatleast1RUofspace
betweenthetwo.HeatfromBIUrisesandcoulddamagetheODU.


5.1.6 BIUpowerconsumption
ThetablebelowshowspowerconsumptionoftheBIU:
Part Unit ConsumptionPower Remark
CommonPart
Shelf
4.8WMCPU
MPSU
MCDU‐ 2.4W
MDBU 1900P+850C 16W
