Figure5.9–InterfaceportbetweenBIUandODU

AttherearpartoftheODU,thenumberofRFPortsandSignalPortsareprintedinorder.Itsagood
ideatolabeltheseincaseadditionalODUsareneeded.












ODUNumbering
RFPort
SignalPort
TX RX
ODUSISO
ODU1 #1 SISO_ODU#1
ODU2 #2 SISO_ODU#2
ODU3 #3 SISO_ODU#3
ODU4 #4 SISO_ODU#4
ODUMIMO
ODU1 #1 MIMO_ODU#1
ODU2 #2 MIMO_ODU#2
ODU3 #3 MIMO_ODU#3
ODU4 #4 MIMO_ODU#4
