Figure5.8–MDBULEDindicatorinformation

MONITORSMAportseenatthefrontpaneloftheMDBUallowsyoutocheckthecurrentlevelofTX
inputandRXoutputsignalsinservicewithoutaffectingmainsignals.
TXMONis‐20dBbelowTXInputpowerandRXMONis‐20dBbelowRXOutputpoweraswell.

5.1.5 ODUInterface
TheBIUsupportsuptofourODUsperplatform.AttherearofBIU,eightRFinputandoutputports
fortheODUsaswellasfourpowerportsforpowersupplyandcommunicationareprovided.Asyou
connecttheODUs,theBIUrecognizestheODUthatisconnectedwithBIU
automatically

LED Description
ON
 Powerisnotsupplied.
 Powerissupplied.
ALM

NormalOperation

AbnormalOperation
